(5) Printer status signals

Error status

RINF1

RINF2

RINF3

1.

Paper out

Low

High

Low

2.

Paper near end

High

High

Low

3.

Head up

High

Low

Low

4.

Head temperature abnormality

High

Low

High

5.

Head voltage abnormality

Low

High

High

6.

Hardware abnormality

High

High

High

7.

NOT

Low

Low

Low

Mark detection abnormality

8.

Normal

Low

Low

High

2. RS-232C

FOR

(1) Connector (CN2)

Connector part number

: B6B-XH-A (J.S.T.) or equivalent

Mating connector part number : XHP-6 (J.S.T.) or equivalent

DESIGN

(2) Connector pin assignment

No.

Signal

I/O

Contents No.

No.

Signal

I/O

Contents No.

1

FG

-

Frame ground

2

RD

NEW

I

Receive data

3

TD

O

Transmission data

4

DTR

O

Data terminal ready

5

GND

-

Signal ground

6

DSR

I

Data set ready

7

SLCTIN

I

Printer select

8

INPRM

I

Reset

Power down cancellation

9

ATF

I

Paper feed request

10

PWD

I

signal

Notes:

•Symbol “——” means a negative logic signal.

•“I” or “O” means a signal direction from the interface board side.

Cutter (CN11)
