Shipping weight (lbs)
Shipping weight (kg)
Shipping Dimensions (HWD/in)
78.3
35.5
9 x 22 x 32.8
Shipping Dimensions (HWD/cm)
22.9 x 55.9 x 83.3
Unit weight (lbs) | 68.8 |
|
|
Unit weight (kg) | 31.2 |
|
|
Unit Dimensions | 3.5 x 17.3 x 26 |
(HWD/in) |
|
|
|
Unit Dimensions | 8.9 x 43.9 x 66 |
(HWD/cm) |
|
|
|
Material of | Steel |
construction |
|
|
|
Form factors | Supports 2U rackmount installation in 4 post racks using included mounting accessories. Add 2POSTRMKITWM for two |
supported | post racks and wallmount installation. Add |
|
|
Cooling method | Fans |
|
|
Battery Access | Battery access panel enables hot swappable battery replacement |
|
|
ENVIRONMENTAL |
|
Relative Humidity | |
|
|
Operating | |
Temperature |
|
|
|
COMMUNICATIONS |
|
Network | Includes USB port (HID enabled), DB9 Serial port (RS232 and contact closure supported) |
monitoring port |
|
|
|
Software and | Includes PowerAlert software, plus USB and DB9 cabling |
cabling included |
|
|
|
SNMP | |
compatibility |
|
|
|
LINE / BATTERY TRANSFER
Transfer time from line power to battery mode
Zero transfer time in
Low voltage transfer to battery power
Switches to battery power as line voltage drops to 80V or less (70V at loads under 70%)
High voltage | Switches to battery power as line voltage increases to 144V or higher |
transfer to battery |
|
power |
|
|
|
SPECIAL FEATURES |
|
EPO port | Supports "Emergency Power Off" via set of dedicated |
|
|
Cold Start | Yes, inverter can be "cold started" to enable temporary AC output during a power failure |
|
|
Appearance | Attractive black steel rackmount housing |
|
|
BATTERY PACK ACCESSORY (optional) | |
Battery Pack | |
Accessory |
|
(optional) |
|
|
|
CERTIFICATIONS |
|
Certifications | Tested to UL1778 (USA), CSA (Canada), NOM (Mexico), FCC Part 15 Class A (EMI) |
|
|
