4. Configuration Options

Configuring SNMP NMS Security

Select SNMP NMS Security from the Management and Communication menu to configure trap managers (see Table 4-22, SNMP NMS Security Options).

Main Menu Configuration Management and Communication

SNMP NMS Security

A table displays→with the network→management systems (with their respective→IP addresses) allowed access to the SNMP FrameSaver unit.

Table 4-22. SNMP NMS Security Options (1 of 2)

NMS IP Validation

Possible Settings: Enable, Disable

Default Setting: Disable

Specifies whether security checks are performed on the IP address of SNMP management systems attempting to access the node. Only allows access when the sending manager’s IP address is listed on the SNMP NMS Security Options screen.

Enable – Performs security checks.

Disable – Does not perform security checks.

Number of Managers

Possible Settings: 1 – 10

Default Setting: 1

Specifies the number of SNMP management systems that are authorized to send SNMP messages to the FrameSaver unit. An IP address must be configured for each management system allowed to send messages. Configure IP addresses in the NMS n IP Address configuration option.

1 – 10 – Specifies the number of authorized SNMP managers.

NMS n IP Address

Possible Settings: 001.000.000.000–126.255.255.255,

128.000.000.000–223.255.255.255, Clear

Default Setting: Clear (000.000.000.000)

Provides the IP address of an SNMP manager that is authorized to send SNMP messages to the unit. If an SNMP message is received from an unauthorized NMS and its IP address cannot be matched here, access is denied and an authenticationFailure trap is generated. If a match is found, the type of access (read-only or read/write) is determined by the corresponding Access Type.

Display Conditions – This option appears for each trap manager specified in the

Number of Trap Managers configuration option.

001.000.000.000 – 223.255.255.255 – Adds or changes the NMS IP address. The first octet of the address cannot be decimal 0 or 127, or greater than 223.

Clear – Fills the NMS IP address with zeros.

9700-A2-GB20-20

December 2002

4-51
