Philips HTB3560 Update software through, Download the latest software, Update the software

Page 27

4 Select [Advanced] > [Software Update] > [Network].

»»If an upgrade media is detected, you are prompted to start or cancel the update.

5 Follow the instruction on the TV to confirm the update.

»»When the software update is complete, the home theater automatically switches off . If it does not, disconnect the power cord for a few seconds and then reconnect it.

Note

•• If the home theater cannot connect to the Philips server, press (Home).

•• Select [Setup] > [Network] > [Network Installation] to set up the network.

Update software through

USB

What you need

A USB flash drive that is FAT or NTFS- formatted, with at least 75MB of memory. Do not use a USB hard drive.

A computer with Internet access.

An archive utility that supports the ZIP file format.

Step 1: Download the latest software

1 Connect a USB flash drive to your computer.

2 In your web browser, go to www.philips. com/support.

3 At the Philips Support website, find your product and locate the Software and drivers.

»»The software update is available as a zip file.

4 Save the zip file in the root directory of your USB flash drive.

5 Use the archive utility to extract the software update file in the root directory.

»»The files are extracted under the UPG_ALL folder of your USB flash drive.

6 Disconnect the USB flash drive from your computer.

Step 2: Update the software

Caution

•• Do not switch off the home theater or remove the USB flash drive during the update.

1 Connect the USB flash drive containing the downloaded file to your home theater.

• Make sure that the disc compartment is closed and no disc inside.

2 Press (Home).

3 Select [Setup], and then press OK.

4 Select [Advanced] > [Software Update] > [USB].

5 Follow the onscreen instructions to confirm the update.

»»Once complete, the home theater automatically switches off . If it does not, disconnect the power cord for a few seconds and then reconnect it.

27EN

Image 27
Contents Register your product and get support at Always there to help youContents Risk of electric shock or fire SafetyCare of the environment Use only microfiber cloth to clean the product3D health warning Care for your productConnectors Main unitSource Remote control Front connectorsRear connectors Options BackRepeat TOP MenuConnect and set up Follow these general guidelines for speakers placementConnect speakers Best quality video Connect to TVOption 1 Connect to TV through Hdmi ARC Option 2 Connect to TV throughOption 2 Connect audio through analog audio cables Connect audio from TV and other devicesOption 3 Connect to the TV through composite video Option 1 Connect audio through a digital optical cableEasyLink controls Set up speakersSet up EasyLink HDMI-CEC control Enable EasyLinkConnect and set up a home network Set up the audioSet up the wired network Set up the wireless network Play buttons Access the home menuUse your home theater DiscsPress OK to confirm Play Blu-ray 3D discBonus View on Blu-ray BD-Live on Blu-rayVOD code for DivX Data filesUSB storage devices SubtitlesPicture options Audio, video, and picture optionsAudio options Video optionsMusical slideshow RadioPicasa web albums Tuning gridMP3 player YouTube videosControl your home theater Smartphone controlBrowse PC through Dlna View slideshowSet up media server software Surround Choose soundPlay files from your PC SoundSound mode Surround sound modeEqualizer Audio settings Change settingsLanguage settings Picture and video settingsSpeaker settings Parental control settingsDisplay settings Energy saving settingsCheck software version Update softwareRestore default settings Update software through the InternetUpdate software through Update the softwareDownload the latest software Audio formats Region codesMedia formats File formatsAmplifier VideoAudio Subwoofer Remote control batteriesRadio Main unitPlay TroubleshootingPicture SoundSubtitles on Press OK Cannot read the contents of a USB storage deviceCinavia notice Wireless network distorted or not foundCopyright NetworkTrademarks Other U.S. and worldwide patents issuedOpen source software Compliance35 EN Language code HDMI-CEC IndexVCD All rights reserved HTB356012UMV1.0

HTB3560 specifications

The Philips HTB3560 is a home theater sound system that delivers an immersive audio experience, complemented by sleek design and cutting-edge technology. This all-in-one unit is designed for those who seek to enhance their home entertainment systems without compromising on space or style.

One of the standout features of the HTB3560 is its powerful 300-watt output, which ensures that users experience dynamic sound whether they're watching movies, playing video games, or listening to music. The system includes a subwoofer that provides deep bass, enhancing the overall audio performance and making it suitable for action-packed films and music with rich low frequencies.

In terms of connectivity, the Philips HTB3560 offers multiple options for users to connect their devices effortlessly. It includes HDMI inputs, allowing for easy synchronization with modern TVs and other devices, as well as USB ports for direct playback of music and video files from flash drives. Additionally, the system features Bluetooth technology, enabling users to stream audio wirelessly from their smartphones or tablets, providing convenience and flexibility in audio playback.

The HTB3560 also supports various audio formats, ensuring compatibility with a wide range of media. It is equipped with a built-in DVD player, which makes it easy to enjoy your favorite movies without needing extra equipment. The device can upscale standard-definition DVDs to near high-definition quality, enhancing viewing experiences even with older media.

Another notable characteristic is the system's ability to provide multiple sound modes, including options for movies, music, and gaming. This versatility allows users to tailor their audio settings according to the content they are consuming, ensuring optimal sound quality regardless of the type of media.

The design of the Philips HTB3560 is both modern and stylish, featuring a compact form that fits seamlessly into various room aesthetics. Its user-friendly interface and remote control make it easy to operate, so users can quickly navigate through settings without fuss.

In summary, the Philips HTB3560 is a feature-rich home theater sound system that combines powerful audio output, versatile connectivity options, and stylish design, making it an excellent choice for anyone looking to elevate their home entertainment experience.
