Page 11

Introduction

Remote Control with Laser Pointer

	30
2	1
2	3
5	4
6	7
9	8
10	11
	11

13		12
14	15	16
		16
17		18
20	19	22
20		22
21	23
24		26
25	27	28
29		28

1.	Laser Indicator Light	16.	Mouse
2.	Power	17.	Volume +/-
3.	Laser Button	18.	Page Up/Page Down
4.	Source	19.	Empowering Key
5.	Resync	20.	RGB
6.	Freeze	21.	Brightness
7.	Hide	22.	Contrast
8.	Mute	23.	Color
9.	Aspect Ratio	24.	VGA
10.	Keystone/Four Directional	25.	Component
	Select Keys	26.	S-Video
11.	Back	27.	Video
12.	Digital Zoom	28.	HDMI
13.	Menu	29.	DVI
14.	Mouse Left Click	30.	Transmit Indicator Light
15.	Mouse Right Click
15.	Mouse Right Click				... English
					... English
