ATEN Technology KVM CS-62 user manual Symptom Possible Cause Action

Page 13

Symptom

Possible Cause

Action

Mouse Not

Switch needs to be

Turn off the computers and unplug the

Detected, or

reset.

KVM cables. Wait five seconds; then

Does Not



plug the cables back in and turn the

Respond



computers on.

Correctly2





Mouse set to Serial

Some mice can be set to act as either





Mode.

a PS/2 or serial mouse. Make sure the





mouse is set to PS/2 mode.









Incorrect Mouse

Check your Device Manager to be sure



Driver.

that the correct driver for your mouse





(obtained from the manufacturer, or





supplied by the operating system), has





been installed.







Video

Resolution and/or

Select a lower resolution and/or

Problems

Bandwidth set too

bandwidth.



high.



1

2

The unit is designed to work with PS/2keyboards. XT (84 key) and AT keyboards will not work.

Some Notebooks, notably the IBM Thinkpad and Toshiba Tecra, have trouble when their mouse and keyboard ports are used simultaneously. To avoid this, only connect the mouse port or the keyboard port. If you connect the mouse port, you will need to use the notebook’s keyboard when the notebook becomes the active computer.

- 11 -

2003-06-20

Image 13
