Enterasys Networks BL-89520ENT, BL-89720ENT, BL-89620ENT Electrical Specifications, AC Power Input

Page 26

Electrical Specifications

Electrical Specifications

AC Power Input

Voltage

90–264 V Autoranging (46 Hz–63 Hz)





Connector

3-pin with Ground





Chassis Grounding

Yes





Power Supply

Single





DC Port Power Output

Power Enabling

IEEE 802.3af





Power Pins

Unused Pairs, Pins 4,5(+), 7,8,(-)





Maximum Power/Port

15.6 W





Maximum Power-all Ports Active

20 Port: 20 x 15.6 W=312 W



10 Port: 10 x 15.6 W=156 W





Port to Port Isolation

1000 Vrms





Overload Protection

If current reaches 400–450mA for 300–400



milliseconds, then the port shuts down.





A-4 Hardware Specifications
