Raymarine Radome Scanners manual General, Transmitter

Page 27

23

Appendix A: Technical specification

RD218 18”Radome scanner unit

General

Approvals





CE - conforms to

1999/5/EC



FCC - conforms to

47CFR Part 2 and Part 80





Dimensions

Φ521 x 247 mm (20.5 x 9.7 in)







Weight

9.5 kg (21 lbs)







Input Voltage

8.7 - 32 V DC (from display unit)







Power Consumption

28 W (9 W Standby)









Environmental

Waterproof to CFR46





Temperature range:

-10° to +55°C



Humidity limit:

up to 95% at 35°C



Maximum wind speed for satisfactory operation:



100 Kts









Maximum Range Scale

24 nm









Transmitter

Transmitter Frequency

9410 +/– 30 MHz









Peak Power Output

2.0 kW (nominal)







Transmitter

Solid-state modulator driving Magnetron







Pulse Length/PRF





Range (nm)

Pulse Length (ns)

PRF (kHz)

0.25 or less

75

3.0

0.50

100

3.0

0.75

150

3.0

0.75 expanded

250

2.5

1.50

350

1.8

3.00

450

1.4

3.00 expanded

600

1.0

6.00 or greater

1.0 μs

740 Hz

Standby Mode

magnetron heater and control left on, all other



services off









Duplexer

Circulator









Image 27
