Using the Network Utility (Continued)
7Select the projector to be transmitted.
The IDs of projectors accessible for transmission will be listed. (When a projector name is set, that name appears instead of MAC address. )
Check the checkbox of the projector you wish to transmit to from this list. And select the virtual display number that you wish to transmit to from
the
icon marked with a number (corresponding to the screen number) is displayed on the selected projector’s screen for a few seconds.
8Click on the
button.
When “Update automatically” is selected in step 3
Screen images are sent consecutively after the
button is clicked. Besides, the sound being played on a computer can be sent to the projector.
When “Update manually” is selected in step 3
A single screen image is sent when the
button is clicked.
●Multiscreen Usage Examples
Example 1)
While projecting data sent from your computer on a screen, you can also display the other data such as a presenter script on your computer so that you can give a presentation without showing any data which you do not wish to let other participants see.
Example 2)
Using only a single computer, you can make an effective presentation by displaying different data stored in the computer via two projectors.
Example 3)
Sending images from a single computer to multiple projectors (up to four projectors), a larger image can be achieved by combining those images.
USB memory
Network and
Note
•The examples shown here are illustrated as projectors are connected to a computer via wireless LAN, however, this also applies for the connection via wired LAN.
•Note that the brightness or the color tint of the projected image may vary depending on each projector. This is an optical characteristic and not a malfunction. (Please adjust with the Image adjustment menu.)
CAUTION
When you use multiple projectors for Multiscreen feature, make sure to leave sufficient space (more than OOcm) between projectors. If you set the projector near
the air exhaust of the other projector, it may cause damage to other units due to heat.
