Compaq 6710b manual Ccfl PPI

Page 18

QuickSpecs

HP Compaq 6710b Notebook PC

Technical Specifications

15.4-inch WSXGA+ wide-viewing angle, anti-glare

Dimensions (W x H)

13.0 x 8.1 in (33.1 x 20.7 cm)

Diagonal Size

15.4 in (39.1 cm)



Surface Treatment

Anti-glare



Contrast Ratio

300:1 (typical)



Refresh Rate

60 Hz



Brightness

200 nit (typical)



Pixel Resolution

Pitch

0.197 mm



Format

1680 x 1050



Configuration

RGB stripe

Backlight

CCFL



PPI

129



Viewing Angle

±60° Horizontal, ± 50° Vertical (minimum)

15.4-inch WXGA anti-

Active Area (W x H)

13.0 x 8.1 in (33.1 x 20.7 cm)

glare

Diagonal Size

15.4 in (39.1 cm)





Surface Treatment

Anti-glare





Contrast Ratio

300:1 (typical)





Refresh Rate

60 Hz





Brightness

200 nit (typical)





Pixel Resolution

Pitch

0.259 mm





Format

1280 x 800





Configuration

RGB stripe



Backlight

CCFL





PPI

98





Viewing Angle

±30° Horizontal, ±10° Vertical (minimum)







15.4-inch WXGA

Active Area (W x H)

13.0 x 8.1 in (33.1 x 20.7 cm)

BrightView

Diagonal Size

15.4 in (39.1 cm)





Surface Treatment

BrightView





Contrast Ratio

300:1 (typical)





Refresh Rate

60 Hz





Brightness

200 nit (typical)





Pixel Resolution

Pitch

0.259 mm





Format

1280 x 800





Configuration

RGB stripe



Backlight

CCFL





PPI

98





Viewing Angle

±30° Horizontal, ±10° Vertical (minimum)









Hard Drives

DA - 12685 Worldwide QuickSpecs — Version 12 — 3/18/2008

Page 18

Image 18
Contents QuickSpecs At a Glance Supported Operating System PreinstalledProcessors CertifiedDisplay Internal GraphicsWindows Vista ExternalIntegrated wireless Broadband WirelessWireless Module Intel Wireless WiFiWireless Technology WiFi Adapter HP Integrated ModuleWith Bluetooth Broadcom 4311BGSecondary battery Out Power connectorDocking connector Connector LED status indicatorsSmbios Version HP BackupRecovery Manager Security Standard FeaturesLife Battery Optional HP Ultra Power SupplyBattery Primary battery Optional HP Extended Life Battery Primary batteryQuickSpecs Memory Expansion SolutionsPower MultiBay II Storage 9.5-mmSecurity EL348AAMemory Upgrades Standard MemoryUp to Slot Quantity Supported Drive Bay Quantity Supported Drive Bay Primary Hard DrivesStand-Alone Power System Unit Dimensions HxWxDWeight TemperatureConnector HP 90W Smart AC DimensionsAdapter Weight EMI and SafetyOptional HP Extended Life Battery Ion battery WeightCcfl PPI QuickSpecs QuickSpecs QuickSpecs DVD/CD-RW Combo Access Times DVD-ROM Drive Access TimesTransfer Mode Max Data TransferDVD+/-RW SuperMulti Access Times DL DriveDL LightScribe Drive 16, 20 or 24-bit Or 20-bitPerformance Features Communications Integrated Broadcom Ethernet FeaturesPower Management Modem Power ManagementWireless Parametric Command SetWireless Protocol Power Power ConsumptionHumidity, Non Operating Configuration UtilitiesWireless Module Wireless Protocol LED ActivityPacket Mode 3945ABG Network Standards Intel PRO/Wireless Wireless LANOutput Power for ConnectionHumidity Configuration UtilityOperating Voltage LED Activity LED Off Radio OFF Solid LED On Radio onIntel Wireless WiFi LinkWireless LAN 4965AGN StandardsDBPSK, DQPSK, CCK, OFDM, BPSK, QPSK, 16-QAM, 64-QAM 4965AG Standards Roaming Output Power for Adapter Broadcom 4311BG Wireless LAN 802.11b/g WiFi Adapter StandardsLED Off Radio OFF Solid LED On Radio on Frequency Support Security1Receiver Sensitivity3 Transmit Power HP Integrated Module BluetoothWith Bluetooth Specification Wireless Technology Dimensions Number of AvailableBluetooth Software Bluetooth ProfilesLink Topology Heat Dissipation 115 VAC 230 VAC 100 VAC Declared Noise Sound Power Sound Pressure EmissionsEnergy Consumption 115 VAC 230 VAC 100 VAC BatteriesEnvironment/supplychain/genspecifications.html Material UsageRecycling End-of-lifeManagement Hewlett-Packard

6710b specifications

The Compaq 6710b is a business laptop that embodies reliability and performance, making it a popular choice among professionals and enterprises. Launched as part of HP's Compaq series, the 6710b targets users who require a balance of power, portability, and durability in a mobile computing solution.

One of the key features of the Compaq 6710b is its robust build quality. The chassis is designed to withstand the rigors of daily use, making it well-suited for business environments. The laptop's spill-resistant keyboard adds an extra layer of durability, ensuring that accidental spills do not lead to catastrophic failures.

In terms of performance, the Compaq 6710b is powered by Intel's Core 2 Duo processors, providing ample computational power for multitasking and running demanding applications. This allows professionals to conduct intensive tasks such as data analysis, presentations, and web conferencing without experiencing significant lag or slowdowns.

The display of the 6710b is another highlight, featuring a 15.4-inch widescreen format. The BrightView technology enhances color vibrancy and clarity, making it an excellent choice for presentations and multimedia applications. The resolution of 1280x800 offers a comfortable viewing experience, suitable for both work and entertainment.

Connectivity options are abundant in the Compaq 6710b. It is equipped with multiple USB ports, an Ethernet port, and VGA output, allowing users to connect an array of peripherals and display devices. It also features integrated Wi-Fi and optional Bluetooth capabilities, enabling wireless connectivity for ease of use in various environments.

Security is a priority in the Compaq 6710b. The device includes features such as a fingerprint reader, which provides an additional layer of security by allowing users to authenticate their identity quickly. This is particularly important for businesses that handle sensitive information and require secure access to data.

The battery life of the Compaq 6710b is respectable for a laptop of its class, offering enough power to last through a full day of work. Users can choose from various battery configurations to optimize performance based on their specific needs.

In summary, the Compaq 6710b stands out for its robust design, solid performance with Intel's Core 2 Duo processors, vibrant display, extensive connectivity options, and strong security features. These attributes make it a solid choice for business professionals seeking a dependable and effective mobile computing solution.
