Compaq 6710b manual Intel Wireless WiFi LinkWireless LAN, 4965AGN Standards

Page 31

QuickSpecs

HP Compaq 6710b Notebook PC

Technical Specifications

Output Power (for

CKK)2

Output Power (for OFDM; power varies by data rate)2

Power Consumption

Power Management

Receiver Sensitivity4

Antenna Connections

Range

Form Factor

Weight

Dimensions

Operating Voltage

Temperature

Humidity

Altitude

Configuration Utility5

15dBm

15dBm

Transmit: 1.8 Watts (max)

Receive: 1.4 Watts (max)

Idle mode3: 150 mW (nominal)

Sleep mode: 30 mW (max)

ACPI compliant power management 802.11 compliant power saving mode

54 Mbps: -72 dBm, 11 Mbps: -88 dBm , 1 Mbps: -97 dBm

2 U.FL type connectors, 50 ohm nominal impedance

802.11 b – Typical

1200 feet – Outdoor Open Area

(@1 Mbps)

300 feet – Indoor, Office environment

802.11 g – Typical

1200 feet – Outdoor Open Area

(@1 Mbps)

300 feet – Indoor, Office environment

PCI-Express MiniCard



0.013 lb (6 g)



0.19x 1.2 x 2.0 in (4.75 x 29.85 x 50.8 mm)

3.3V +/- 9%, 1.5V +/- 5%

Operating

32° to 176° F (0° to 80° C)

Non-operating

–40° to 176° F (–40° to 80° C)

Operating

10% to 90% (non-condensing)

Non-operating

5% to 95% (non-condensing)

Operating

0 to 10,000 ft (3,048 m)

Non-operating

0 to 50,000 ft (15,240 m)

Microsoft Windows 2000 or XP

Choice of Configuration Utility:

Microsoft Windows XP Wireless Network Connection Manager Intel PROSet for Microsoft Windows 2000 or XP (required for Cisco Compatible Extensions support)

Microsoft Windows Vista

Microsoft Windows Vista Wireless Network Connection Manager

LED Activity

LED Off – Radio OFF; Solid LED On – Radio ON

1.Check latest software/driver release for updates on supported security features.

2.Maximum output power may vary by country according to local regulations.

3.In Power Save Polling mode.

4.Receiver sensitivity is measured at a packet error rate of 8% for 802.11b (CKK modulation) and a packet error rate of 10% for 802.11a/g (OFDM modulation).

5.WLAN supplier's client utility is required for Cisco Compatible Extensions support with Microsoft Windows 2000 or XP. WLAN may also be compatible with certain third-party software supplicants.

Intel Wireless WiFi LinkWireless LAN

IEEE 802.11a

4965AGN

Standards

IEEE 802.11b





IEEE 802.11g





IEEE 802.11n (draft 1.02)

DA - 12685 Worldwide QuickSpecs — Version 12 — 3/18/2008

Page 31

Page 30 Page 32
Image 31
Page 30 Page 32
Contents QuickSpecs At a Glance Certified Operating System PreinstalledProcessors SupportedExternal GraphicsWindows Vista Display InternalIntel Wireless WiFi Broadband WirelessWireless Module Integrated wirelessBroadcom 4311BG WiFi Adapter HP Integrated ModuleWith Bluetooth Wireless TechnologyConnector LED status indicators Out Power connectorDocking connector Secondary batterySecurity Standard Features HP BackupRecovery Manager Smbios VersionOptional HP Extended Life Battery Primary battery Power SupplyBattery Primary battery Life Battery Optional HP UltraQuickSpecs MultiBay II Storage 9.5-mm Expansion SolutionsPower MemoryEL348AA SecurityStandard Memory Memory UpgradesUp to Slot Quantity Supported Drive Bay Primary Hard Drives Quantity Supported Drive BayTemperature System Unit Dimensions HxWxDWeight Stand-Alone PowerEMI and Safety HP 90W Smart AC DimensionsAdapter Weight ConnectorIon battery Weight Optional HP Extended Life BatteryCcfl PPI QuickSpecs QuickSpecs QuickSpecs Max Data Transfer DVD-ROM Drive Access TimesTransfer Mode DVD/CD-RW Combo Access TimesDL Drive DVD+/-RW SuperMulti Access TimesDL LightScribe Drive Or 20-bit 16, 20 or 24-bitModem Power Management Communications Integrated Broadcom Ethernet FeaturesPower Management Performance FeaturesPower Power Consumption Command SetWireless Protocol Wireless ParametricLED Activity Operating Configuration UtilitiesWireless Module Wireless Protocol Humidity, NonPacket Mode Connection Intel PRO/Wireless Wireless LANOutput Power for 3945ABG Network StandardsLED Activity LED Off Radio OFF Solid LED On Radio on Configuration UtilityOperating Voltage Humidity4965AGN Standards Intel Wireless WiFi LinkWireless LANDBPSK, DQPSK, CCK, OFDM, BPSK, QPSK, 16-QAM, 64-QAM 4965AG Standards Roaming Output Power for Adapter 802.11b/g WiFi Adapter Standards Broadcom 4311BG Wireless LANLED Off Radio OFF Solid LED On Radio on Security1 Frequency SupportReceiver Sensitivity3 Number of Available HP Integrated Module BluetoothWith Bluetooth Specification Wireless Technology Dimensions Transmit PowerBluetooth Profiles Bluetooth SoftwareLink Topology Batteries Declared Noise Sound Power Sound Pressure EmissionsEnergy Consumption 115 VAC 230 VAC 100 VAC Heat Dissipation 115 VAC 230 VAC 100 VACMaterial Usage Environment/supplychain/genspecifications.htmlHewlett-Packard End-of-lifeManagement Recycling

6710b specifications

The Compaq 6710b is a business laptop that embodies reliability and performance, making it a popular choice among professionals and enterprises. Launched as part of HP's Compaq series, the 6710b targets users who require a balance of power, portability, and durability in a mobile computing solution.

One of the key features of the Compaq 6710b is its robust build quality. The chassis is designed to withstand the rigors of daily use, making it well-suited for business environments. The laptop's spill-resistant keyboard adds an extra layer of durability, ensuring that accidental spills do not lead to catastrophic failures.

In terms of performance, the Compaq 6710b is powered by Intel's Core 2 Duo processors, providing ample computational power for multitasking and running demanding applications. This allows professionals to conduct intensive tasks such as data analysis, presentations, and web conferencing without experiencing significant lag or slowdowns.

The display of the 6710b is another highlight, featuring a 15.4-inch widescreen format. The BrightView technology enhances color vibrancy and clarity, making it an excellent choice for presentations and multimedia applications. The resolution of 1280x800 offers a comfortable viewing experience, suitable for both work and entertainment.

Connectivity options are abundant in the Compaq 6710b. It is equipped with multiple USB ports, an Ethernet port, and VGA output, allowing users to connect an array of peripherals and display devices. It also features integrated Wi-Fi and optional Bluetooth capabilities, enabling wireless connectivity for ease of use in various environments.

Security is a priority in the Compaq 6710b. The device includes features such as a fingerprint reader, which provides an additional layer of security by allowing users to authenticate their identity quickly. This is particularly important for businesses that handle sensitive information and require secure access to data.

The battery life of the Compaq 6710b is respectable for a laptop of its class, offering enough power to last through a full day of work. Users can choose from various battery configurations to optimize performance based on their specific needs.

In summary, the Compaq 6710b stands out for its robust design, solid performance with Intel's Core 2 Duo processors, vibrant display, extensive connectivity options, and strong security features. These attributes make it a solid choice for business professionals seeking a dependable and effective mobile computing solution.
