Asus 27T1EH, 24T1EH user manual

Page 27

-Game: best choice for game playing with Splendid™ Video Intelligence Technology.

-Scenery: best choice for scenery photo display with Splendid™ Video Intelligence Technology.

Contrast: to adjust the contrast of the displayed picture.

Brightness: to adjust the luminance of the display.

Colour: to adjust the colour of the displayed picture deeper or paler; this function is active only in Standard Splendid™ mode and when VGA input is not in use.

Sharpness: to adjust the sharpness of the displayed picture; this function is active only in Standard Splendid™ mode.

Tint: to make the displayed picture more red or green; this function is active only when input is NTSC by Video port.

You can NOT adjust Colour, Sharpness or Tint for VGA input.

Colour Temperature: to select the colour temperature among warm, mild, cool, and user’s modes. In user’s mode, you can adjust the level of the red, green, and blue to define your preferred white colour.

VGA: to adjust the image parameters for VGA input.

-Auto Adjust: to let the display automatically optimize the VGA input image.

-Horizontal Pos.: to adjust the horizontal position of the VGA input image.

-Vertical Pos: to adjust the vertical position of the VGA input image.

-Clock: to adjust the frequency of the VGA input image.

-Phase: to adjust the phase of the VGA input image.

Noise Reduction: to specify the intense of noise reduction function among Off, Low, Moderate, High and Auto.

ASCR: to switch on and off the ASUS Smart Contrast Ratio function.

Back Light Control: to adjust the back light intensity.

Reset Picture: to reset all the picture parameters.

ASUS LED TV Monitor T1 Series

17

Image 27
