Asus VK191 manual Specifications summary, Panel Type Panel size Max. Resolution Brightness

Page 20

3.2Specifications summary

Panel Type

Panel size

Max. Resolution

Brightness

Contrast Ratio (Typ.) / (Max.) Viewing angle(H/V) CR>10 Display colors Response time

Webcam SPLENDID™ Video Intelligence Technology SPLENDID™ selection Auto adjustment

Color temperature selection Skin-Tone selection Digital input

Analog input

Audio-in port

Color

Speaker (Built-in)

Power LED

VESA wall mount

Tilt

Kensington lock

Voltage rating

TFT LCD

19" wide screen

WXGA+ 1440 x 900

300cd/m2

1000:1 / 3000:1 (with ASCR ON)

160˚/160˚

16.7M

5ms

1.3Mega pixel / VGA (VK191D only)

Yes

5 video preset modes (by hotkey)

Yes (by hotkey)

5 color temperatures

3 skin-tones

DVI-D with HDCP (VK191T / VK191N)

D-Sub

3.5mm Mini-jack (VK191T / VK191S) Black

1W x 2 Stereo, RMS (VK191T / VK191S) Blue (On)/ Amber (Standby)

100 x 100mm (purchased separately)

-5˚~+20˚

Yes

AC: 100~240V

*Specifications are subject to change without notice.

3-4

Chapter 3: General Instruction
