Samsung manual X72 240pin DDR3 Sdram Registered Dimm

Page 19

General Information

DDR3 SDRAM

x72 240pin DDR3 SDRAM Registered DIMM

9.50

				133.35 ± 0.15
				128.95		C		(2X)3.00
				128.95
9.76	10.9	18.92		32.40	18.93		9.74

				Register					30.00 ± 0.15
	2.50							2.30	17.30
	54.675		A	B				2.30	17.30
	54.675

	47.00				71.00

Units : Millimeters

Max 4.0

1.0 max

1.27 ± 0.10

5.00

3.80

2.50

1.50±0.10

Detail A

2.50 ± 0.20

0.80 ± 0.05

0.2 ± 0.15

1.00

Detail B

10.9

	0
	.5
R	0
R

Detail C

0.4

2x 2.10 ± 0.15

Register

Address, Command and Control lines

October 2009
