Connecting to External Devices

Recommended Connection, Resolution & Picture Mode

HDMI Connection, 3840 x 2160@30Hz, dynamic

HDMI Connection (480p, 576p, 720p, 1080i, 1080p, UHD@24Hz/30Hz)

HDMI supports ultra high definition (UHD) input, high definition input, and HDCP (High-bandwidth Digital Content Protection). Some devices require HDCP in order to display HD signals.

	HDMI
	1
Display	2
	3

	HDMI
	1
Display	2
	3

HDMI signal cable

VCR/DVD/Set-top Box

AUDIO

IN

HDMI to DVI signal cable

VCR/DVD/Set-top Box

Note: Dolby Digital is not supported.

AUDIO

IN

13
