Aspect Ratio

1

Press the MENU button on the remote control,

then use the UP/DOWN arrow button to select





the Special menu. Or press RATIO button to



instantly access the Aspect Ratio .

2

Press ENTER or the RIGHT arrow button to acti-

vate the Special menu.



3

Use the UP/DOWN arrows to choose Aspect

Ratio.

4

Press ENTER or the RIGHT arrow button to move

into the Aspect Ratio selection menu. Use the





UP/DOWN arrow buttons to select the right ratio



for your viewing environment:

SETUP

VIDEO

AUDIO

TIME

SPECIAL

LOCK

Aspect Ratio G

Language

Captions

Caption/Text

Key Lock

Cinema

Demo

MENU Prev.

4:3

16:9

Horizon

Zoom1

Zoom2

4:3 - Choose when you want to view a pic- ture with an original 4:3 aspect ratio, with black bars appearing at both the left and right sides.

16:9 - Choose when you want to adjust the picture horizontally, in a linear proportion to fill the entire screen. (Useful for viewing 4:3 formatted DVDs.)

Horizon - Choose when you want to adjust the picture in a non-linear proportion. The picture is more enlarged at both sides, to create a spectacular view.

Zoom1 - Choose when you want to view the picture without any alteration. However, the top and bottom portions of the picture will be cropped.

Zoom2 - Choose when you want the picture to be altered, both vertically extended and vertically cropped. The picture taking a halfway trade off between alteration and screen coverage.

5

Press EXIT to save and return to TV viewing or

press the ENTER button to save and return to





the previous menu.

For RGB-PC source, you can select either 4:3 or 16:9 aspect ratios.

For RGB-DTV (720p, 1080i) or Component 1-2 (720p, 1080i) sources,, you can select either 4:3, 16:9 or Zoom1-2 aspect ratios.

Aspect ratio is changed to 16:9 automatically for 720p or 1080i formats from component input1/2, RGB, or DVI sources.

After connecting external equipment to the TV, don’t display a still picture for a long time on the screen. Doing so may damage the TV screen.

Lets you choose the way that an analog picture with a 4:3 aspect ratio is displayed on your TV 16:9 aspect ratio TV screen. When you receive an analog picture with a 4:3 aspect ratio on your 16:9 TV, you need to specify how the picture is to be displayed according to your preference.



TV

VCR CABLE DVD SAT



MODE



LIGHT

POWER



TV/VIDEO

FRONT

DVI



COMP1

COMP2

RGB



1



2

3



4



5

6

2/4/5

7



8

9

ENTER



0

FLASHBK









MUTE





SURF



SAP





VIDEO



VOL

CH





PIP PIPCH- PIPCH+

SWAP

1

RATIO

CC

FREEZE PIP INPUT









1/3/4

2/4



1

MENU

EXIT

1/3/4

PLAY

5



PAUSE STOP RECORD









REW

FF







SKIP

P A G E 3 9
