Polaroid LCD-1550 operation manual S I C E R a T I O N S, Basic operations

Page 9

B A S I C

O P E R A T I O N S

WHEN THE TV IS INITIALLY POWERED ON,

When your TV is powered on for the first time, the left figure is displayed.

1 Pressing VOL up/down (Ï/Ã) buttons makes a selection between AIR or CABLE mode which automatically starts a channel search.

2 Wait until the searching ends.

!

• If you press power button while channel searching, this process stops and goes back to initial status.

1 SWITCHING ON/OFF

SWITCHING ON

1If the indicator is not lit, the TV set is powered off. You must press the POWER button of the TV set.

2Press the POWER button on the remote controller, or VOL (É ) / CH (É ) button on the TV set when the indicator is red. The TV set will be switched on and the indicator will be changed to green.

basic operations

With the remote controller, you can select the mode as below.

TV/VIDEO button : Selection for TV/VIDEO/S-VIDEO input mode.

PC button : Selection for PC monitor input mode.

COMPONENT button : Selection for Component input mode.

!

If CH(É/ ) buttons are pressed in external mode, it turns to TV mode.

3 VOLUME CONTROL

Adjust the volume with VOL (Ï/Ã) buttons.

TO MUTE THE SOUND

Press the MUTE button on the remote controller to cut the sound off. The MUTE will be displayed for 3 seconds. By pressing either the MUTE button or VOL (Ï/Ã) buttons, you can get sound back.

4 CHANNEL SELECTION

The TV set has 68 channels [AIR02 ~ AIR69] in AIR mode and 125 channels [CATV01 ~ CATV125] in CATV mode. (Refer to next page for each selection.)

!

If you don't use the set for extended periods of time, unplug the AC cord from power outlet.

SWITCHING OFF

1To set the TV set back to stand-by mode, press the POWER button on the remote controller or press the MENU button on the TV set for 2 seconds. The indicator will become red.

2Press the POWER button on the TV set to switch the TV set off completely.

*If you turn the TV off, the present time that you have set will disappear.

DIRECT SELECTION

The numeric buttons are used for direct channel selection.

To select two-digit channels, press the second number button within 2 seconds after the first number.

To select 3-digit channels, press ‘+100’ button before pressing the rest of number buttons in order.

• Channel number in green : Memorized channels by automatic

search or added channels by user

2 TV/AV MODE SELECTION

By pressing the TV/VIDEO button on the TV set, you can change the mode as follows:

TV VIDEO S-VIDEO COMPONENT PC TV ....

Channel number in white : Skipped channels by automatic

search or deleted channels by user

UP/DOWN SELECTION

You can also select a memorized channel by pressing the CH (É/ ) buttons.

14

15
