Polaroid LCD-1550 operation manual Troubleshooting

Page 17

TROUBLESHOOTING

G

U

I

D

E

Please check the following items before asking for repair service.



Symptom



Check items

Neither picture



- Check the contact of sockets is all right.

nor sound.



- Check the TV main power is on.

Picture is OK,



- Check the Volume control is set to minimum or mute.

but no sound.







Sound is OK, but



- Check the color control and adjust it properly.

no color.



- Check the program is in color or in black & white.

The picture is



-

Check the antenna is installed correctly and if not, adjust the

overlapped image.



antenna toward the broadcasting station.







- Check the “FINE TUNE” is set up correctly and if not, adjust the









fine tuning properly.

Picture has “snow

-

Check the antenna or its connection is correct and if not,

noise”.







correct the antenna fault or connection cable fault.







- Check if car traffic or neon sign disturbs the sound effect.

Stripes on



-

Check the susceptible interference by other electronic devices

picture.





such as radio and television and keep magnetic or electronic









devices away from the TV.

Bad stereo or SAP

-

Long distance from the station or other radio waves can

sound.







generate bad sound reception. If so, change the mode to









Mono.

Remote control



- Check if the batteries in the Remote control die.

does not



-

Check if any object between IR sensor of the TV and the

work.







Remote control does not obstruct.





Troubleshooting Guide

IN PC MODE





Symptom



Check items

“OUT OF RANGE”

-

Check the resolution and frequency of your PC. Then, adjust

appears on the



them to optimum condition for LCD TV ; 1024 x 768 and 60Hz.

screen.

-

Refer to the table of PC mode input format indicated on page





22. (Not being registered resolution and frequency on the table





won’t be displayed.)

“NO SIGNAL” appears

- Ensure that the signal cable is firmly connected to PC and TV.

on the





screen.





Image is not

-

Adjust the PHASE control. (Refer to the PC ADJUSTMENT of

clear.



page 23.)

Image is not

-

Adjust the H-POSITION, H-SIZE and V-POSITION control. (Refer

centered.



to the PC ADJUSTMENT on page 23.)

30

31

Page 16 Page 18
