Daewoo DLP-20W2, DLP-20J1, DLP-20D7 instruction manual

Page 24

Channel searching

-Select the “Frequency” function.

-Press, and hold for more than 1second, the remote control CURSOR RIGHT (A20) LEFT (A7) buttons to start up [down] manual tuning.

-Searching will stop automatically at the next channel found (to stop tuning, press the re- mote control MENU button (A19).

Note: You can directly locate a program by entering the data into the “channel” or the “fre- quency” function.

Enter station name

It is possible to enter your own choice of name for each program.You can change an existing name, or enter a name where none exists. If none exists “- - - - - - -” will be shown in the Install menu, and program status display.

-Select the “NAME” function.

-Select one of the 7 character positions by using the remote control CURSOR RIGHT (A20) / LEFT (A7) buttons to move the cursor.

-Then use the CURSOR UP (A6) /DOWN (A21) buttons to select the desired character for that position.

-Repeat the last two instructions for other positions, as desired.

-Once the name has been entered, press the OK button (A18) to store it. The name will be memorised to the program number currently shown on the “Store To” line. The “Store To” program number will highlight in red briefly.

TV system modification

If necessary, you can modify the TV system :

-Select “system” function.

-Adjust choosing between FRANCE (L/L’), GB (I), EURO (B/G), E/ EURO (D/K) systems. Then, the program displayed on the screen is changed to the chosen system.

Perform fine tuning

-If you are unable to get a good picture or reasonable quality sound due to poor reception, it is possible to perform fine tuning.

-Select the “frequency” function.

-Press, for less than 1 second, the remote control CURSOR RIGHT(A20) [LEFT(A7)] buttons to perform up [down] fine tuning in steps of 0.05MHz (50 kHz).

Store program in memory

-Select the “store to” function

-Enter the program number you want to store to either by using the remote control CURSOR RIGHT (A20) / LEFT (A7) buttons, or directly by using the remote control NUMBER 0...9 but- tons (A3).

-Press the OK button (A18) to confirm.

Remarks: this function can also be used if you want to copy a program already memorised to another program number.

24

Page 23 Page 25
Image 24
Page 23 Page 25
Contents PAL B/G, D/K, I/I Helpline Number 0870 100Risk of Electric Shock Do not Open Disposal of Used Electrical & Electronic EquipmentSafety Precautions Contents Safeguards Supplied Accessories Remote controller Functional OverviewFront Local ControlRear Inserting Batteries into the Remote Control Unit PreparationMains Connection Connecting the TV Directly to AN Aerial Aerial ConnectionAerial Connection with VCR Connecting external equipment TV/AV Mode Selection AV Input Jack AV2Video Input Jack Scart Jack AV1Automatic Tuning Start UpLanguage Menu ScriptionSwitching On TV Set Switching Off TV SetSwitching on TV SET Daily UseProgram Selection From 0 to Sound ControlPicture Control Sleep FunctionOFF Clock Setting Default Zoom ControlFormat Selection Child LockHow to use the sub-menus Menus DescriptionMain Menu LanguagePicture Menu Sound MenuInstall Menu Equalizer MenuEdit Menu Page Features Menu Wake up functionENTERING/LEAVING Teletext Mode TeletextSelection Useful Teletext FunctionsTeletext Format Picture & Sound Control Page Wall/Arm Mounting Troubleshooting Specifications ANT. in COAXIAL-TYPE Reception Channel

DLP-20J1, DLP-20D7, DLP-20W2 specifications

Daewoo, a renowned name in the electronics industry, has developed a range of digital video projectors that cater to the needs of both business professionals and home entertainment enthusiasts. Among the most notable models in their lineup are the DLP-20W2, DLP-20D7, and DLP-20J1. Each of these projectors incorporates advanced technologies and distinctive features that set them apart in the marketplace.

The Daewoo DLP-20W2 stands out with its impressive brightness and vivid color reproduction, making it an excellent choice for presentations in well-lit environments. This model boasts a high native resolution, enabling sharp and detailed images that enhance the viewing experience. The DLP-20W2 is equipped with a user-friendly interface, allowing for seamless navigation through its various settings. It supports multiple input options, including HDMI and VGA, ensuring compatibility with a wide range of devices.

Moving on to the DLP-20D7, this projector is designed with versatility in mind. It features an advanced cooling system that prolongs the life of the lamp, making it suitable for extended use. The DLP-20D7 also incorporates Android-based software, allowing users to access streaming services and applications directly from the projector without the need for external devices. This feature makes it particularly appealing for those looking to enhance their home viewing experience with smart functionality.

Lastly, the DLP-20J1 combines portability with performance. This model is lightweight and compact, making it easy to transport for business meetings or media events. Despite its size, the DLP-20J1 does not compromise on image quality, providing clear and dynamic visuals. It includes built-in speakers, which add convenience for presentations where external audio systems are not available. The projector's comprehensive connectivity options make it adaptable to various multimedia setups.

In conclusion, Daewoo's DLP-20W2, DLP-20D7, and DLP-20J1 projectors represent a blend of innovative technology and practical features. The DLP-20W2 excels in brightness and compatibility, the DLP-20D7 offers smart functionality and durability, while the DLP-20J1 prioritizes portability without sacrificing performance. Each model caters to specific needs, making Daewoo a valuable player in the digital projection market. Whether for professional or personal use, these projectors provide solutions that enhance visual communication and entertainment experiences.
