Zenith ZRY-316 warranty Finalize, Disc Label, Disc Protect, AutoPlay

Page 24

Finalize

Finalizing ‘fixes’ the recordings in place so that the disc can be played on a regular DVD player or com- puter equipped with a suitable DVD-ROM drive. Finalizing a Video mode disc creates a menu screen for navigating the disc. This is accessed by pressing DISC MENU/LIST or TITLE.

Caution

Once you have finalized a DVD-R and DVD+R disc, you cannot edit or record anything else on that disc except DVD+RW. However, you can record and edit a DVD-RW disc by choosing [Unfinalize] option.

1.Select the [Finalize] option then press B.

2.Press ENTER while [Finalize] is selected. Finalize menu appears.

3.Select [OK] then press ENTER.

The Recorder starts finalizing the disc.

Note:

Finalization can take up to 3-4 minutes or more depending on the type of disc, how much is recorded on the disc, and the number of titles on the disc.

Tips:

•If you load a DVD-RW that has already been finalized, you can ‘Unfinalize’ it by choosing [Unfinalize] from the Finalize menu. After doing this, you can edit and re-record onto the disc.

•You cannot unfinalize a DVD-R and DVD+R disc.

•If [Disc Protect] option is set to [ON], the finalize is not available. To finalize, set [Disc Protect] option to [OFF].

Disc Label

Use the Disc Label feature to enter a name for the disc. This name appears when you load the disc and when you display disc information on-screen.

•The Disc label can be up to 32 characters long.

•For discs formatted on a different Recorder, you will see only a limited character set.

1.Select the [Disc Label] option then press B. [Edit] icon is highlighted.

2.Press ENTER. Keyboard menu appears.

To enter characters, see page 44.

Disc Protect

Depending on the type of disc you are using, Disc Protect allows you to preserve your recordings in a variety of ways:

•DVD+RW : Prevents editing, erasing, or overwriting of existing recordings. Allows regular recording.

•DVD+R : Prevents editing or erasing of existing recordings. Allows regular recording.

•DVD-RW (VR mode) : Prevents editing, erasing, and regular recording.

Notes:

•Disc Protect is not compatible with DVD-RW discs in Video mode or DVD-R discs.

•If you need to unlock a disc to make edits, select [OFF].

AutoPlay

When you load a DVD with AutoPlay turned on, the Recorder will bypass the Disc menu and trailers and start playing the movie automatically.

Set [AutoPlay] to [ON] or [OFF].

24
