Memorex MT2245 manual AUDIO/VIDEOCord, Stereo Connection

Page 18

DVD CONNECTIONS (CONTINUED)

Follow the instructions below to connect a DVD player toREARyour OFtelevisionTV using the Cr, Cb, Y jacks. (CABLES NOT INCLUDED.)

AudioFromOut

AudioFromComponentVideoCableComponentOut AudioToInCableDVDPLAYECRomponentVideoToIn

1.Connect the left and right audio cable from the DVD’s Audio OUT jacks to the TV’s AV2 left and right Audio IN jacks.

2.Connect a video cable from the DVD’s Y, Pb, Pr OUT jacks to the TVs AV2 DVD IN (Cr, Cb, Y) jacks.

3.Press the AV button until VIDEO2 appears on the TV screen and press PLAY on the VCR to watch a tape.

STEREO CONNECTION

Follow the instructionsSTEREObelow to connect a stereo system to your televisionREAR. (CABLESOFTVNOT INCLUDED.)

AUDIOToStereo'sINjacks

FromTVAUDIO

AUDIO/VIDEOCord

OUTjacks

1.Connect the left and right audio cable from the TV’s left and right Audio OUT jacks to the stereo system’s left and right Audio IN jacks.

2.Refer to the stereo system’s owner’s manual for instructions.

17
