Page 19

TV and Cable Box

Some cable TV systems use scrambled or encoded signals that require a cable box to view all channels. If you subscribe to such type of service, use this connection.

Cable box

Connections

From cable/ antenna

LINE OUT

VIDEO AUDIO L AUDIO R

Rear of TV

1	3

S VIDEO

VIDEO

(MONO)

1 Connect the coaxial cable from your cable service to the IN jack on your cable box.

2 Connect a coaxial cable (not supplied) from the OUT jack on your cable box to the VHF/UHF jack on your TV.

Using your TV with this connection

❏Program your Sony remote control to operate your cable box (see page 5).

❏To activate your remote, press (FUNCTION button) to operate your cable box. Then

use the 0 9 buttons or CH+/- buttons to change the channels. In order to do this, first program your remote control, then use the Channel Fix feature to set your TV to channel 3 or 4

(see page 41).
