RCA L19HD41 warranty Channel Banner, Parental Controls and V-Chip, Chip US and Canada

Page 20

3 Using TV Features

Note: Parental control settings are not available for HDMI 1, HDMI 2, CMPT, or PC INPUTS. These settings must be set in the connected componentÕs parental controls.

Channel Banner

There are several indicators that may appear when you press the INFO button on the remote control. This display is called the Channel Banner. The following list describes the items on the Channel Banner screen (left to right and top to bottom).

A135Mono 480i Unrated 1:14 PM

A 135

If the channel is analog, A is displayed. If itÕs a digital channel, D isdisplayed. The



channel, sub-channel (if available for digital channels) and channel name or label



youÕre currently viewing are displayed.

Mono

Displays whether the current channel is being broadcast in stereo or mono. If the



current channel is digital, this space will be blank.

SAP

If the current channel is analog, this shows if it is broadcasting SAP (Second Audio



Program) information. If the current channel is digital, this area shows the language, if



provided by the broadcaster.

480i

Broadcast signal resolution.

Unrated

Rating information of the current program.

Parent Control The Parent Control state (locked or unlocked) of the current program or channel.

1:14 PM

Current time.

Parental Controls and V-Chip

The choices in the US V-Chip and Canada V-Chip menus involve software inside your TV, referred to as V-Chip, which allows you to block TV programs and movies. TV programs can be blocked by age-based ratings, such as TV-MA (See page 22). If available, TV programs can also be blocked by content, such as adult language (L) (See page 22). Movies can only be blocked by age-based ratings (See page 23). Once you block programs, you can unblock them by entering a password. By default, the software inside your TV is turned off or unlocked. For instructions to lock V-Chip, see page 21.

V-Chip - US and Canada

V-Chip reads the programÕs age-based rating (TV-MA,TV-14, etc.) and content themes (Violence (V), Adult Language (L), etc.). If you have blocked the rating and/or content themes that the program contains, you receive a message that the channel is currently blocked. Change the channel or press OK to enter your password and temporarily deactivate the parental controls.

Broadcasters are not required to provide content themes, so programs received with no content themes are blocked only if you block their age-based rating. You can also block programs that have been given an Exempt rating, and programs that are considered unrated. See page 34 for the US and Canada ratings explanations.

20

Chapter 3 Using TV Features
