External Equipment Connections
Choose Your Connection
There are several ways to connect your television, depending on the components you want to connect and the quality of the signal you want to achieve. The following are examples of some different ways to connect your TV with different input sources.
Connecting to HDMI Device
Using an HDMI or HDMI/DVI Cable: HD connection(up to 1080p)
We recommend using the HDMI connection for the best quality HD picture.
Available devices: DVD player,
BD/DVD player/
HD cable/Sat.box
HDMI OUT
DVI OUT
HDMI IN PC AUDIO IN
A
B
C
When using an HDMI/DVI cable connection, you must use the HDMI IN jack for video. A DVD player,
The picture may not display normally(if at all)or the audio may not work if you connect an external device that uses an older version of HDMI mode to the TV. If such a problem occurs, ask the manufacturer of the external device about the HDMI version and, if out of date,request an upgrade.
Be sure to purchase a certified HDMI cable, Otherwise, the picture may not display or a connection error may occur.
