Sharp LC70LE757U, LC70LE650U Picture Settings, AV Mode Changing Pic.Quality, OPC Setting

Page 26

On-Screen Display Menu

Picture Settings

Adjusts the picture to your preference with the following picture settings.

NOTE

• For operating the on-screen display menu, see page 22.

Selected item

c button

d button

Backlight

The screen

The screen



dims

brightens

Contrast

For less

For more



contrast

contrast

Brightness

For less

For more



brightness

brightness

Color

For less color

For more color



intensity

intensity

Tint

Skin tones

Skin tones



become

become



reddish

greenish

Sharpness

For less

For more



sharpness

sharpness

You can select "3D Brightness Boost" while in 3D mode. (For the LE857U, LE757U and LE755U models) (See page 34.)

For resetting all Picture adjustment items to the factory preset values, press a/b to select "Reset", press ENTER, press a/b to select "Yes", and then press

ENTER.

AV MODE (Changing Pic.Quality)

The audio and video settings can be changed to suit the program or input content being watched.

NOTE

The selectable items vary depending on the input source and on the model of your TV.

For details of the selectable items in 3D mode, see page 34. (For the LE857U, LE757U, LE755U, LE657U and LE655U models)

You can select AV MODE by pressing AV MODE on the remote control unit. See page 19 for details of AV MODE settings.

OPC Setting

Automatically adjusts the brightness of the screen.

Off: The brightness is fi xed at the value set in "Backlight".

On: Automatically adjusts.

On:Display: Displays the OPC effect on the screen while adjusting the brightness of the screen.

NOTE

When set to "On", the Optical Picture Control (OPC) senses the surrounding light and automatically adjusts the backlight brightness. Make sure nothing obstructs the OPC sensor, which could affect its ability to sense surrounding light.

When set to "On:Display", OPC effect displays on the screen while the OPC adjusts the screen brightness.

OPC:

OPC:

Advanced Picture Settings

This TV provides various advanced functions for optimizing the picture quality.

C.M.S.

(Color Management System)

Color tone is managed using the six-color adjustment setting.

C.M.S.-Hue:This is a standard to adjust the color either more reddish or more bluish in tone.

C.M.S.-Saturation:Increases or decreases the saturation of a selected color.

C.M.S.-Value:A higher value makes the image brighter.

A lower value makes the image darker.

NOTE

For resetting all adjustment items to the factory preset values, press a/b to select "Reset", and then press

ENTER.

Color Gamut Range

(for the LE857U, LE757U, LE755U and C7500U models)

You can set the color gamut range.

Standard: Standard color gamut.

Expanded: More vivid colors with expanded color gamut.

NOTE

"Color Gamut Range" is only available when AV MODE is set to "MOVIE" or "MOVIE (3D)".

Color Temp. (Color Temperature)

For a better white balance, use color temperature correction.

High: White with bluish tone

Mid-High:

Middle:

Mid-Low:

Low: White with reddish tone

Low (Xenon), Low (Carbon arc): Available only when AV MODE is set to "VINTAGE MOVIE" MODE. Use one of these items to make picture color become more reddish. (For the LE857U, LE757U, LE755U and C7500U models)

White balance can be adjusted between a maximum of +30 and a minimum of –30 for each color temperature.

R Gain (LO/HI)/G Gain (LO/HI)/B Gain (LO/HI)

Fine tuning the color temperature

To fi ne tune the color temperature, set "10 Point Setting" to "On".

You can adjust the "Position" setting. Adjust the set color temperature from +1 to +10.

White balance can be adjusted between a maximum of +30 and a minimum of –30 for each color temperature.

NOTE

When "Position" is set to "10", you can adjust the white balance between –30 and 0.

For resetting all adjustment items to the factory preset values, press a/b to select "Reset", and then press

ENTER.

Motion Enhancement

Use Motion Enhancement to view fast-action video more clearly.

Selected item

Description

AquoMotion960

Turn the LED backlight on or

AquoMotion480

off for 240Hz drive display.

240Hz

For obtaining a clearer image.

AquoMotion240

Turn the LED backlight on or

off for 120Hz drive display.



120Hz High

For obtaining a clearer image.

120Hz Low



Off

Original image.

LE857U models AquoMotion960/240Hz/AquoMotion240/120Hz High/120Hz Low/Off

LE757U and C7500U models AquoMotion480/AquoMotion240/120Hz High/120Hz Low/Off

LE755U models

240Hz/AquoMotion240/120Hz High/120Hz Low/Off

LE657U and LE655U models AquoMotion240/120Hz High/120Hz Low/Off

LE650U and C6500U models

120Hz High/120Hz Low/Off

NOTE

"Motion Enhancement" may cause image noise. If this occurs, turn the function "Off".

When AV MODE is set to "VINTAGE MOVIE" MODE, "GAME" or "PC", or PC format is being input, "Motion Enhancement" is not available.

Game Type

(for the LE857U, LE757U, LE755U and C7500U models)

You can adjust picture quality according to the type of the game you are playing.

Standard: Optimizes picture quality for standard video games.

High Motion: Optimizes picture quality for high motion video games.

NOTE

"Game Type" is not available depending on the input signal type.

24

LC-80LE857U_757U_657U_E.indd 24

2013/02/21 13:36:01
