TUNER SETTINGS

Introduction

Switching Analog Mode /

Digital Mode

You can easily switch between the analog TV (NTSC) and digital TV (ATSC) with the remote control.

Press [DTV/TV] on the remote control.

• The analog mode and digital mode switch alternately.

Note

When you switch from the analog mode to the digital mode, it may take awhile until the digital channel selection is completed. The following screen is displayed while switching the mode.

DTV 2-1

Now Scanning

Channel Selection

Select channels by using [CH / ] or [the Number buttons] on remote control.

[CH / ]

Use [CH / ] to change the channel.

[the Number buttons]

Press the channel number with [the Number buttons] to select a channel you want to watch.

<Analog TV channels>

Enter the channel number with [the Number buttons] to select a channel you want to watch.

For 1-digit number

e.g.) 2 ch: [0] + [2], [2] + [-]or

[2]+ leave it for 2 seconds.

For 2-digit number

e.g.) 25ch:

[2] + [5]

<Digital TV channels>

Enter the major and minor channel number with [the Number buttons] to select a channel you want to watch.

For 1-digit number

e.g.) 2-2 ch:





major channel

[0]

+ [2] or [2] + [-]

minor channel

[0]

+ [2], [2] + [-] or



[2] + leave it for 2 seconds.

For 2-digit number



e.g.) 35-16ch:





major channel

[3]

+ [5]

minor channel

[1]

+ [6]

If you enter 1 digit for major channel and leave it for 2 seconds, the number will be taken as the major channel and lowest minor channel of the major channel will be displayed.

If there is no minor channel input, lowest minor channel of the major channel will be displayed.

Note

In digital TV broadcasting, 2 or more channels, called minor channels, are simultaneously broadcast on one main channel, called major channel.

About minor-channel broadcasting:

There may be different programs being broadcast on minor channels through a single channel from ATSC. You can watch each minor channel program being broadcast by selecting one of the minor channels.

Disc Connections Basic Setup Management Recording Playback Editing Function

NTSC

CH4

18:00

18:30

19:00

19:30

20:00

ATSC

DTV4-1Smallest Smallest

CH CH

DTV4-1 DTV4-2 DTV4-3

DTV4-1 Smallest DTV4-3

CH

DTV4-1 DTV4-2 Smallest

CH

Setup Others

: change automatically

: change manually by using [CH / ]

EN 33
