JVC AV-14A10,AV-14F10, AV-20N10, AV-21A10, AV-21D10, AV-21F10 Display, Off Timer, Eco Sensor

Page 11

Remote control buttons and functions

Display

You can continuously display the current channel number or VIDEO mode on the screen.

Press the DISPLAY button.

To turn the display off, press the DISPLAY button again.

When selecting a channel or VIDEO mode with no input signal, indication of selected channel or VIDEO mode becomes fixed on the screen.

Off Timer

You can set this TV to turn off automatically within a specified period of time.

Repeatedly press the OFF TIMER button to select the period of time.

You can set the period of time a maximum of 120 minutes in 10 minute increments.

1 minute before the Off Timer turns off the TV, GOOD NIGHT! displays.

Eco Sensor

<AV-14A10 does not have this function.>

You can adjust this TV so that the screen automatically adjusts to the optimum contrast according to the brightness of your room. This function reduces eye strain and the power consumption of this TV.

Repeatedly press the ECO SENSOR button to select the desired mode.

DIGITAL ECO SENSOR

DISPLAY:

The Eco Sensor function will work.

In this mode, the clover mark indicating the brightness of your room is dis- played for several seconds each time the brightness changes. The number of clover marks displayed on screen increases as your room becomes darker.

To display the remaining time:

Press the OFF TIMER button once.

To cancel the Off Timer:

Press the OFF TIMER button to return the period of time to 0.

The Off Timer will not turn off the TV’s main power.

DIGITAL ECO SENSOR:

The Eco Sensor function will work. However, in this mode, the clover mark will not be displayed even if the brightness of your room changes.

DIGITAL ECO SENSOR OFF:

The Eco Sensor function will not work.

Muting

You can turn the volume off instantly. This is convenient when answering the phone or when you have visitors. Press the MUTING button.

To return the sound, press the MUTING button again.

11

Image 11
