Connecting to a Video Camera

The following illustration shows you how to connect the TV to a camcorder. Actual connections may vary according to the make and model of the device. Refer to the user’s manual included with the camcorder for more detailed instructions.

		AV1		DC-IN	ANT
AV2	R	L	VIDEO

		AV1	DC-IN
AV2	R	L		ANT
			VIDEO

AV2

4-in-1 cable

WB S

S-Video connector

B

R

W

Y

AV connectors

Note: When connecting the S-Video connector and AV connectors at the same time, the priority is given to the S-Video connector.

Cables and connectors are color-coded (black, red, white, yellow).
