HANNspree LT11-23A1 user manual Adjusting On-Screen Display OSD Settings

Page 39

11

Adjusting On-Screen Display (OSD) Settings

The On-Screen Display (OSD) menu system provides a quick and simple method to adjust your TV's setting. This chapter describes how to change each of the available settings. The OSD menu can be accessed through either the side control panel or the remote control.

Button Descriptions	Side Panel Control

Menu	MENU
CH Up	∧
CH Down	∨
VOL Up	+
VOL Down	–

The following sections explain how to adjust settings in the OSD menus using the side panel control.

OSD Setting Menus

MENU

MAIN MENU


AUDIO

TV

MISCELLANEOUS

EXIT

: SELECT : ENTER MENU : CLOSE

Press MENU to enter the OSD The Main Menu appears. Main Menu screen.

Notes:

•Press the MENU button to open and close the OSD menu at any time.

•Alternatively, select the CLOSE option in the menu to return to the previous menu.

38
