Appendix A: PC Input Typical Display Modes

The display has a maximum resolution of 1680X1050 (optional), frequency range of 56-75 Hz. The following table is an illustration of some of the typical video display modes.

Your TV may not support different resolutions. Supported resolution modes are listed below.

If you switch your PC to an unsupported mode, a warning OSD will appear on the screen.

Mode

Resolution

Frequency (Hz)



Horizontal

Vertical











1

640

480

60

IBM, VGA



2

720

400

70

IBM, VGA



3

800

600

56

VESA



4

800

600

60

VESA



5

640

480

72

VESA



6

640

480

75

VESA



7

800

600

72

VESA



8

800

600

75

VESA



9

1024

768

60

VESA

OPTIONAL

10

1024

768

70

VESA

11

1024

768

75

VESA

12

1280

720

60

VESA

13

1280

768

60

VESA

14

1360

768

60

VESA



15

1680

1050

60

*















- 41 -
