JVC HR-J461MS specifications Activate Index Search, Skip Over Unwanted, Sections, EN Playback

Page 14

14ENPLAYBACK(cont.)

1 2 3

4 5 6

7 8 9

0

LAY 1

REW

3

MENU

2

4

TIMER

30 SEC

FF

OK

PUSH JOG

Index Search

Your recorder automatically marks

index codes at the beginning of£ 2 each recording. This function gives

you quick access to any one of 9 index codes in either direction.

NOTE:

Before starting, make sure the recorder is in the Stop mode.

ACTIVATE INDEX SEARCH

1 Press PUSH JOG Þor %(ª or £) on the remote control. "ª 1" or "£ 1" is displayed on screen and search begins in the corresponding direction.

●To access index codes 2 through 9, press PUSH JOG

Þor % repeatedly until the correct index number is displayed.

Ex.: To locate the beginning of B from the current position, press PUSH JOG Þtwice.

To locate the beginning of D from the current position, press PUSH JOG %once.

Current position

A	B		C	D E		F
–2		–1	1	2		3
		%		%		Index			number
		%		%

●When the specified index code is located, playback begins automatically.

Skip Search

			SKIP OVER UNWANTED
	1		SECTIONS
			Press 30 SEC 1 to 4 times during playback. Each press
			initiates a 30-second period of fast-motion playback.
			Normal playback resumes automatically.

NOTE:

To return to normal playback during a Skip Search, press PLAY.
