JVC HR-J258E, HR-J458E Basic Playback, Load a Cassette, Point, Start Playback, Stop Playback

Page 13

PLAYBACK

EN13

Basic

Playback

Turn on the TV and select the VIDEO channel (or AV mode).

FF

LAY

REW

STOP/EJECT



The easiest, most basic operation possible with your video recorder is tape playback. Already-recorded signals on a video tape are read by your video recorder and displayed on your TV just like a TV programme.

1



LOAD A CASSETTE

Make sure the window side is up, the rear label side is



facing you and the arrow on the front of the cassette is



point toward the recorder. Don’t apply too much





pressure when inserting.











● The recorder power comes on automatically and the





counter is reset to 0:00:00.





● If the record safety tab has been removed, playback





begins automatically.











FIND PROGRAMME START

2



POINT

If the tape is advanced past the start point, press REW.



To go forward, press FF.

3



START PLAYBACK

Press PLAY. “BEST” appears blinking in the recorder's



display panel during automatic tracking. (☞ pg. 20)

4



STOP PLAYBACK

Press STOP on the remote or STOP/EJECT on the



recorder’s front panel. Then press STOP/EJECT to



remove the cassette.







1

4

7

LAY 1

REW

STOP

2 3

5 6

8 9

0

?

3

2

4

FF

Usable cassettes

●Compact VHS camcorder recordings can be played on this video recorder. Simply place the recorded cassette into a VHS Cassette Adapter and it can be used just like any full-sized VHS cassette.

●This video recorder can record on regular VHS and Super VHS cassettes. However, it will record and play back regular VHS signals only. It is not possible to play back a recorded Super VHS tape.

Page 12 Page 14
Image 13
Page 12 Page 14
Contents HR-J458E HR-J258E To HR-J458E Owners Safety PrecautionsTo HR-J258E Owners Do not place the recorderBasic Connections Check ContentsSituate Recorder Connect Recorder to MainsInternational Telephone Country Code Auto Set UpFor Suisse For Belgium Just Clock on Initial SettingsLanguage Exit Video Channel SET Mode Access Video Channel SET ModeVideo Channel Set SET Video ChannelPress TV Prog until the display panel shows With AV ConnectionOUT Now the video channel is set to offENABLE/DISABLE ON-SCREEN Display Access Main Menu ScreenOn-Screen Displays Turn on the RecorderPower Save Mode Return to Normal Screen Colour System SetSET, then press OK or% Pointer next to Colour SYSTEM, then press OKLoad a Cassette Basic PlaybackPoint Start PlaybackPlayback Playback FeaturesSearch Activate HIGH-SPEED SearchOverride Automatic Tracking Adjust TrackingManually Return to AutomaticRepeat Playback Basic Recording Reset Counter Recording FeaturesSelect Channel to Watch Display Remaining TimeInstant Timer Recording ITR Engage ITR ModeSET Recording Duration Press Record on the recorderPreparation S.T. Picture SystemPointer next to B.E.S.T Then press OK or%to setPlayback RecordingOr press Record on the recorder Timer Programming Press SP/LP Start Time Express Timer ProgrammingEnter Programme Stop TimeEnter Channel Position Timer ModeEngage RECORDER’S VPS/PDC RecordingPress ä, then press Check, Cancel And Replace ProgrammesPress Again to check More information. Each Time you press Next programmesAuto Timer Auto SP→LP Timer HR-J458E onlyAutomatic Satellite Programme Recording Prog REC ModeSET Tape Speed J458E OnlyEdit From a Camcorder Edit To Or From Another Video Recorder SET Recording DECK’S Input ModeStart Source Player Start Recording DeckRecorder AV2 Select SettingSatellite Tuner Unit Connection To Satellite TunerBack of Recorder Select Input Mode Connecting Using a DecoderConnect Decoder SET TunerAuto Channel Set Tuner SetSET, then press OK or% Press %Þ to place the pointer next to the languageView Confirmation Screen Perform Auto Channel SETStoring Channels Manually Delete a Channel When Receiving a Scrambled BroadcastChange Station Channel Position Press %Þ until the item you want to move beginsSwitch Stations Access ManualSelect Item Channel SET ScreenTV Station And ID List Select Channel to FINE-TUNE Fine-Tuning Channels Already StoredPress %Þ until the channel you want to tune begins blinking Number Showview SetupEnter Receiving Channel Position Number Guide Program Number SetAccess Clock SET Screen Access Initial SET ScreenClock Set SET Date and TimeStart Clock Operation SET Clock Data Source Channel PositionSet the TV to its AV mode If you are using the AV connectionSet the TV receiver to the Video ClearTimer Recording Questions and Answers Index Rear View Remote Control Helical scan system HR-J458E Maximum recording timeRotary two-head helical scan IN/OUT x 1, IN/DECODER xMemo Area Code for Belgium HR-J458/258EArea Code for Suisse Language Code

HR-J458E, HR-J258E specifications

The JVC HR-J258E and HR-J458E are part of JVC's renowned lineup of VHS video cassette recorders, known for their reliability and quality. These models offer essential features and advanced technologies aimed at providing a superior viewing experience and ease of use.

The HR-J258E is a compact yet feature-rich VCR that supports NTSC video formats. It comes equipped with essential functions like a built-in tuner, facilitating direct recording from television broadcasts. The one-touch timer recording feature simplifies the process of capturing your favorite programs, enabling users to set it up with minimal effort. The model also incorporates JVC's reliable auto head cleaner, reducing maintenance and ensuring optimal playback quality.

On the other hand, the HR-J458E elevates the user experience with additional features that cater to more advanced needs. It includes a more advanced still image function, allowing users to freeze frames for clearer inspection or for creative projects. With multiple recording speeds, the HR-J458E offers flexibility for users, enabling them to choose between standard quality for longer recordings or higher quality for shorter clips.

Both models showcase a robust build and a user-friendly interface, making them suitable for all ages. The front-loading design allows for easy access, and a programmable timer offers convenient scheduling for recording tasks. Additionally, the models are designed to minimize power consumption, aligning with modern users' awareness of energy efficiency.

In terms of connectivity, the JVC HR-J258E and HR-J458E include multiple inputs and outputs, catering to a variety of devices such as TVs, external antennas, and audio systems. This versatility ensures an integration into existing home entertainment setups without hassle.

Overall, the JVC HR-J258E and HR-J458E represent a blend of practicality, user-focused technology, and reliability that has defined JVC’s reputation in the world of home entertainment. While the HR-J258E focuses on the essential features that facilitate recording and playback, the HR-J458E enhances the user experience with additional functionalities and improved versatility. Both models serve as excellent choices for individuals looking for dependable and high-quality VHS recorders to relive their favorite memories captured on tape. Whether for archiving family videos or enjoying classic films, these VCRs stand out in their category, offering features that meet a wide range of user needs.
