JVC HR-J258E, HR-J458E specifications Recording, Playback, Or press Record on the recorder

Page 21

Recording

1

START RECORDING

Press and hold RECORD and press PLAY on the remote,

or press RECORD on the recorder.



DURING B.E.S.T.









B.E.S.T. COMPLETE

●The recorder spends approximately 7 seconds assessing the condition of the tape, then begins recording.

NOTES:

●With HR-J458E:

The B.E.S.T. system works for both SP and LP modes only after a tape has been inserted and the Record mode is first initiated. It does not work during recording.

With HR-J258E:

The B.E.S.T. system works only after a tape has been inserted and the Record mode is first initiated. It does not work during recording.

●The B.E.S.T. system does not work while Auto Satellite Prog recording is in progress (☞ pg. 28).

●In the case of timer recording, the B.E.S.T. system works before recording is initiated.

●Once the cassette is ejected, the B.E.S.T. data is cancelled. The next time the cassette is used for recording, B.E.S.T. is re- performed.

●Pressing the recorder's RECORD button while "BEST" is displayed does not start Instant Timer Recording

(☞ pg. 19).

ATTENTION

Since the B.E.S.T. system works before recording actually starts, there is a delay of approximately 7 seconds after RECORD and PLAY on the remote are pressed, or RECORD on the recorder is pressed. To make sure you record the desired scene or programme in its entirety, first perform the following steps:

1)Press and hold PAUSE and press RECORD to engage the RECORD PAUSE mode.

●The recorder then automatically checks the condition of the tape and, after approximately 7 seconds, re- enters RECORD PAUSE.

2)Press PLAY to start recording.

●If you want to bypass the B.E.S.T. system and begin recording immediately, set “B.E.S.T.” to “OFF” in step 4 on page 20.

EN21

Playback

The recorder assesses the quality of the tape once you initiate playback.

START PLAYBACK

1 Press PLAY.

●The recorder adjusts the playback picture quality based on the quality of the tape in use.

●B.E.S.T. is active during Auto Tracking. “BEST” appears blinking on the recorder’s display panel.

NOTES:

●When watching a tape recorded with “B.E.S.T.” set to “ON”, it is recommended that you leave B.E.S.T. on during playback as well.

●When watching a rental tape or one recorded on another video recorder, or when using this recorder as the player for editing, set B.E.S.T. to your preference by performing steps 1 through 5 on page 20.

●"BEST" only appears at the beginning of automatic tracking. Even though it doesn't appear after that, the B.E.S.T. function is operative.

Page 20 Page 22
Image 21
Page 20 Page 22
Contents HR-J458E HR-J258E To HR-J458E Owners Safety PrecautionsTo HR-J258E Owners Do not place the recorderBasic Connections Check ContentsSituate Recorder Connect Recorder to MainsInternational Telephone Country Code Auto Set UpFor Suisse For Belgium Just Clock on Initial SettingsLanguage Exit Video Channel SET Mode Access Video Channel SET ModeVideo Channel Set SET Video ChannelPress TV Prog until the display panel shows With AV ConnectionOUT Now the video channel is set to offENABLE/DISABLE ON-SCREEN Display Access Main Menu ScreenOn-Screen Displays Turn on the RecorderPower Save Mode Return to Normal Screen Colour System SetSET, then press OK or% Pointer next to Colour SYSTEM, then press OKLoad a Cassette Basic PlaybackPoint Start PlaybackPlayback Playback FeaturesSearch Activate HIGH-SPEED SearchOverride Automatic Tracking Adjust TrackingManually Return to AutomaticRepeat Playback Basic Recording Reset Counter Recording FeaturesSelect Channel to Watch Display Remaining TimeInstant Timer Recording ITR Engage ITR ModeSET Recording Duration Press Record on the recorderPreparation S.T. Picture SystemPointer next to B.E.S.T Then press OK or%to setRecording PlaybackOr press Record on the recorder Timer Programming Press SP/LP Start Time Express Timer ProgrammingEnter Programme Stop TimeEnter Channel Position Timer ModeEngage RECORDER’S VPS/PDC RecordingPress ä, then press Check, Cancel And Replace ProgrammesPress Again to check More information. Each Time you press Next programmesAuto Timer Auto SP→LP Timer HR-J458E onlyAutomatic Satellite Programme Recording Prog REC ModeSET Tape Speed J458E OnlyEdit From a Camcorder Edit To Or From Another Video Recorder SET Recording DECK’S Input ModeStart Source Player Start Recording DeckRecorder AV2 Select SettingConnection To Satellite Tuner Satellite Tuner UnitBack of Recorder Select Input Mode Connecting Using a DecoderConnect Decoder SET TunerAuto Channel Set Tuner SetSET, then press OK or% Press %Þ to place the pointer next to the languageView Confirmation Screen Perform Auto Channel SETStoring Channels Manually Delete a Channel When Receiving a Scrambled BroadcastChange Station Channel Position Press %Þ until the item you want to move beginsSwitch Stations Access ManualSelect Item Channel SET ScreenTV Station And ID List Fine-Tuning Channels Already Stored Select Channel to FINE-TUNEPress %Þ until the channel you want to tune begins blinking Number Showview SetupEnter Receiving Channel Position Number Guide Program Number SetAccess Clock SET Screen Access Initial SET ScreenClock Set SET Date and TimeStart Clock Operation SET Clock Data Source Channel PositionSet the TV to its AV mode If you are using the AV connectionSet the TV receiver to the Video ClearTimer Recording Questions and Answers Index Rear View Remote Control Helical scan system HR-J458E Maximum recording timeRotary two-head helical scan IN/OUT x 1, IN/DECODER xMemo Area Code for Belgium HR-J458/258EArea Code for Suisse Language Code

HR-J458E, HR-J258E specifications

The JVC HR-J258E and HR-J458E are part of JVC's renowned lineup of VHS video cassette recorders, known for their reliability and quality. These models offer essential features and advanced technologies aimed at providing a superior viewing experience and ease of use.

The HR-J258E is a compact yet feature-rich VCR that supports NTSC video formats. It comes equipped with essential functions like a built-in tuner, facilitating direct recording from television broadcasts. The one-touch timer recording feature simplifies the process of capturing your favorite programs, enabling users to set it up with minimal effort. The model also incorporates JVC's reliable auto head cleaner, reducing maintenance and ensuring optimal playback quality.

On the other hand, the HR-J458E elevates the user experience with additional features that cater to more advanced needs. It includes a more advanced still image function, allowing users to freeze frames for clearer inspection or for creative projects. With multiple recording speeds, the HR-J458E offers flexibility for users, enabling them to choose between standard quality for longer recordings or higher quality for shorter clips.

Both models showcase a robust build and a user-friendly interface, making them suitable for all ages. The front-loading design allows for easy access, and a programmable timer offers convenient scheduling for recording tasks. Additionally, the models are designed to minimize power consumption, aligning with modern users' awareness of energy efficiency.

In terms of connectivity, the JVC HR-J258E and HR-J458E include multiple inputs and outputs, catering to a variety of devices such as TVs, external antennas, and audio systems. This versatility ensures an integration into existing home entertainment setups without hassle.

Overall, the JVC HR-J258E and HR-J458E represent a blend of practicality, user-focused technology, and reliability that has defined JVC’s reputation in the world of home entertainment. While the HR-J258E focuses on the essential features that facilitate recording and playback, the HR-J458E enhances the user experience with additional functionalities and improved versatility. Both models serve as excellent choices for individuals looking for dependable and high-quality VHS recorders to relive their favorite memories captured on tape. Whether for archiving family videos or enjoying classic films, these VCRs stand out in their category, offering features that meet a wide range of user needs.
