Page 7

hours,

minutes, seconds & frames ahead of the rest.





03H 02M 52S 05F 43

SF audio























scrubbing























JUST LIKE TAPE

dv40 and pd-6











The large high-resolution (200 pulses per











rotate) jog/shuttle dial and clever digital











tracking technology result in incredible













































audio scrubbing.

SEAMLESS INTEGRATION

Plus, with it’s on-board Ethernet networking capabilities











It really is just like using tape.













PD-6 8cm DVD-RAM discs can be played out on a DV-40 by

recorded files can easily be transferred around the post











24bit

simply removing them from the caddy and placing in the

house’s media network.















DVD-RAM tray. It‘s this kind of simple and seamless

In addition to UDF PD-6/DV40 files, DV40 can also read files























integration which makes the PD-6 / DV40 such a

created on other manufacturers recorders in FAT16, BWF











Resolution

formidable production team.

Interleaved format complete with timecode information.











The DV40 provides high precision scrubbing for PD-6 DVD-

















192kHz

RAM discs, easy ethernet networking plus extensive audio /



































timecode manipulation.









D















Frequency





interfacing

FLEXIBLE RECORDING















mode used. In addition, other formats























The DV40 is capable of recording up to























24bit / 192kHz depending on recording





INCREDIBLY WELL CONNECTED

on XLR connectors, while the standard complement of











offered: (see chart on page 7)





Each of the four audio channels feature balanced XLR

timecode, video sync and word clock inputs and outputs











16bit / 44.1kHz, 16bit / 48kHz, 24bit /





inputs individually switchable between +4dBu and –10dBV

are also present. Interoperability and system integration is











44.1kHz, 24bit / 48kHz, 24bit / 88.2kHz,





and the highest quality 24bit/192kHz AD converters. The

taken care of via 9 and 15 pin RS-422 connectors, the











24bit / 96kHz and 24bit / 176.4kHz





outputs are provided on both balanced XLR again with

latter also providing a 12V 400mA power source for future

















24bit/192kHz DA converters as well as 1/4" unbalanced

remote control applications. Both these interfaces comply













ency selector

















phone jacks for easy monitoring hook-up.

to the Sony 9-Pin protocol for standard VTR emulation and

































Flexible headphone monitoring is provided on the front

Fostex’s own extended instruction set.

















panel with switchable source selection for Track 1+2,

The 10Base-T/100-BaseTX Ethernet (RJ-45) port and a

















Track 3+4, Track 1+3/2+4 and each track individually.

firmware-selectable GPI (General Purpose Interface) for

















Digital input and output for all four channels is taken care

remote control, fader starts and file search rounds off this









DV40 is equipped with 10/100Base-T Ethernet





of via the AES/EBU format (doubling up for 176.4/192kHz)

most comprehensive set of interface capabilities.





















as standard. Once the IP address is set DV40





















files will be available via your media network.

P R O F E S S I O N A L D V D M A S T E R R E C O R D E R
