Page 18

Operation

Setup Menu Options

EZ Scan (Channel Search)

-Automatically finds all channels available through antenna or cable inputs, and stores them in memory on the channel list.

-Run EZ Scan again after any Antenna/Cable connection changes.

SETUP

EZ Scan



ANT 1

ANT 2



ANT 1

ANT 2





ANT 1

ANT 2



ANT 1

ANT 2



Ch.Edit



























VIDEO

DTV Signal



Air





Cable







Cable

Air



Air

Cable





























Ch. Label

Select antenna input,

Select antenna input,

Select DTV cable band,

Select antenna input,

Select antenna input,

AUDIO

Main Input

press



press



press

press



press

























































TIME

Sub Input

Analog/DTV Air

Analog/DTV Air

1. STD

Analog/DTV Air

Analog/DTV Air

Front Display

Analog/DTV Cable

Analog/DTV Cable

2. HRC

Analog/DTV Cable

Analog/DTV Cable



OPTION

SET ID

Analog+DTV Air(ANT2)

Analog+DTV Air(ANT2)

3. IRC

Analog+DTV Air(ANT2)

Analog+DTV Air(ANT2)



Analog+DTV Cable(ANT2)

Analog+DTV Cable(ANT2)



Analog+DTV Cable(ANT2)

Analog+DTV Cable(ANT2)







LOCK



MENU

Prev.



MENU

Prev.





MENU

Prev.



MENU

Prev.



1.Press the MENU button and then use D / E button to select the SETUP menu.

2.Press the G button and then use D / E button to select EZ Scan.

3.Press the G button and then use D / E button to select antenna input (Based on your connections to antenna 1-2).

• Analog/DTV Air:

Watching the Over-the-air, cable, and digital over-the-air signals via antenna 1 input port

• Analog/DTV Cable:

Watching the Over-the-air, cable, and digital cable signals via antenna 1 input port

• Analog+DTV Air (ANT2):

Watching the Over-the-air, and cable signal via antenna 1 input port and the digital over-the-air signal via antenna 2 input port

• Analog/DTV Cable (ANT2):

Watching the Over-the-air, and cable signa lvia antenna 1 input port and the digital cable signal via antenna 2 input port

*Cable Service Band Note: Select STD=Standard, HRC=HRC Band, or IRC=IRC Band. (For further band information, contact your cable service provider.)

4.Press the OK button to begin the channel search.

Allow EZ Scan to complete the channel search cycle for TV, CATV, and DTV/CADTV.

Channel Edit

-Create two different types of channel lists in memory: “Custom list” and “Surf" (Favorite) channel list” from the default channel list created from the EZ Scan channel search.

-A custom list can be created by toggling each channel on or off with OK button. Once a channel is highlighted, you will be able to see whether the channel is currently added or deleted by referring to the small window at the top-left corner of the screen. You can create your own Surfchannel list with up to 10 channels. It appears at the bottom-left corner of the screen. Use the SURF button on the remote control when a channel is highlighted, to add or delete the channel from the Surf channel list.

-You can create your SURF channel list from the channel list memorized from EZ Scan.

-CATV is available for 1-125 channel.

1.Press the MENU button and then use D / E button to select the SETUP menu.

2.Press the G button and then use D / E button to select Ch. Edit.

3.Press the G button. You will now see a screen filled with channel numbers and a preview picture.

4.Use D / E / F / Gbutton to select a channel and then use the OK button to add or delete it. Press SURF to add the channel to the Surf List.

5.Press EXIT button to return to TV viewing or press MENU button to return to the previous menu.



SETUP

EZ Scan







Ch.Edit

G





VIDEO









DTV Signal







Ch. Label





AUDIO



Main Input











TIME

Sub Input





Front Display











OPTION

SET ID

























LOCK









MENU

Prev.













Selection ( G or ) leads you to the channel edit screen.

18
