Page 10

TO RECORD A SCRAMBLED/UNSCRAMBLED CHANNEL

1.Set the TV/VCR channel selector to the output channel of the Cable Converter Box or Satellite Box. (Ex. CH3)

2.Select the channel to record from your Cable Converter Box or Satellite Box.

EXTERNAL INPUT MODE

When using an external input signal (another VCR or video camera), connect the player’s audio/video out- put cables to the AUDIO IN/ VIDEO IN jacks of your TV/VCR. Then press the CHANNEL K or L button until “AUX” appears on the screen.

NOTE: “AUX” is found below the

lowest memorized channel.AUX (Example: CH2)

INSTALLING THE BATTERIES

1)Open the battery compartment cover by pressing the cover on the remote unit in the direction of the arrow.

2)Insert 2 “AA” penlight batteries into the battery

compartment in the direction indicated by the polarity (+/-) markings.

3)Replace the cover.

SET UP FOR USE

You can program the tuner to scan all the channels you receive in your area.

NOTE: Channel memory programming is NOT needed when connected to a cable box or satellite box. Just select the TV/VCR channel selector to the output channel of the cable box or satellite box (Ex CH3). Then select the channel to be viewed on the Cable Box or Satellite Box.

CHANNEL SET UP FOR THE

FIRST TIME

1Plug in the TV/VCR power cord

Plug the TV/VCR power cord into a standard AC outlet.

NOTE:

4Begin auto preset

Press the PLAY/K or STOP/L but- ton to point to “AUTO PRESET”. Then press the F.FWD/B button. The tuner scans and memorizes all active channels in your area.

– SET UP –

LANGUAGE [ENGLISH] ESPAÑ OL

BAUTO PRESET

If some digits appear in the corner of the screen, press the POWER button without unplugging the power cord.

2Turn on the TV/VCR

Press the POWER button to turn on the TV/VCR

3Select “ENGLISH” or “ESPAÑ OL”

Select “ENGLISH” or

– SET UP –

“ESPAÑOL”=Spanish using the

B LANGUAGE

F.FWD/B or REW/s button. “[ ]”

[ENGLISH] ESPAÑ OL



indicate the selected language.

AUTO PRESET

NOTES:

The TV/VCR distinguishes between standard TV channels and cable channels.

If you want to play or record a video tape BEFORE presetting the tuner, you must press the MENU button on the remote control. To preset the tuner again, see “CHANNEL SET UP AGAIN” on page 12.

The TV/VCR may recognize TV channels to be CATV channels by the receiving conditions. In this case, try auto preset again in the fine receiving conditions.

5After scanning

The tuner stops on the lowest memorized channel. If you want to recall the selected channels, you can select the desired channel directly with the remote control number buttons or CHANNEL K or Lbutton.

- 10 -

EN

9I03
