INSTALLATION

Connecting VHF and UHF

Antennas, continued

If you use a different 300-ohm	3 Plug the combiner into the
antenna with twin flat leads, fol-	terminal on the rear panel of
low the directions below, but skip	the TV/VCR.
step 1.

1Push the stem of the rod

antenna into the antenna mount.

2Connect both antenna leads to a combiner.

Connecting Cable TV Systems to the TV/VCR

Choose one of the sections below for connecting a cable system.

✓This TV/VCR is cable-ready; you don’t need a converter for basic cable channels.

Cable Without a

Converter Box

To connect cable without a converter box:

1Plug the incoming cable into the terminal on the rear panel of the TV/VCR.

Cable With a

Converter Box

If your cable company scrambles some channels and requires you to use a converter box for only those channels, use these instructions.

You will need the following pieces of equipment, which you can purchase from an electronics store:

•A two-way splitter

•An RF (A/B) switch

•Four lengths of coaxial cable

1Plug the incoming cable into the 2-way splitter.
