Toshiba 37RV525RZ, 32RV525RZ Using the TV’s features, Selecting the video input source to view

Chapter 6: Using the TV’s features

Selecting the video input source to view

To select the video input source to view:

1無 Press on the remote control or TV control panel.

2無 And then either:

a)Press 0–7; or

b)Repeatedly press  on the remote control and then press to change the input; or

c)Repeatedly press on the remote control or TV control panel to change the input.

The current signal source displays in the top right corner of the Input Selection screen.

Input Selection			ANT/CABLE
0	ANT/CABLE
1	Video 1
2	Video 2
3	ColorStream HD1
4	ColorStream HD2
5	HDMI 1 REGZA-LINK
6	HDMI 2
7	HDMI 3
8	PC
0	- 8 / INPUT	to Select	Navigate

Note:

••You can label the video input sources according to the specific devices you have connected to the TV ( “Labeling the video input sources” at right).

••Sources can be “hidden” ( “Labeling the video input sources” at right).

••“No Video Signal” will appear randomly on the screen if no signal is received in video input mode.

••If CEC device is connected to a HDMI input, the REGZA-LINK icon will appear.

If a REGZA-LINK device with HDMI switching capability (e.g. Audio Receiver) is connected to the HDMI input:

Press on the remote or TV control panel repeatedly to highlight HDMI 1, HDMI 2, or HDMI 3. If the connected CEC device has any connected devices, a separate device selection popup window will appear.

Press repeatedly to highlight the desired input source, and then press .

Note:

••When selecting REGZA-LINK input sources from the popup window using , some REGZA-LINK devices may automatically turn on.

••When selecting input sources using ,

you will have to press to actually select a particular device from the popup window.

Labeling the video input sources

You can label each video input source according to the type of device you connected to each source, from the following preset list of labels:

•– – (default label)

•Audio Receiver

•Cable

•Compact Disc

•DTV

•DVD

•Game Console

•HDMI Switch (HDMI inputs only)

•Laser Disc

•Satellite/DSS

•VCR

•Video Recorder

•Hide (to hide an unused input in the Input Selection screen and in the Channel Browser™ Inputs list)

Note: If you select PC in the Input Selection screen, you can choose only “– –”, “Game Console”, or “Hide” as the label.

To label the video input sources:

1無 Press and open the Preferences menu.

2無 Highlight Input Labeling and press .

Preferences

CC Selector		Off
Base CC Mode	Off	CC1
Digital CC Settings		CC2
Input Labeling		CC3
Channel Labeling		CC4
Menu Language	English	T1
Channel Browser Setup		T2

REGZA-LINK Player Control

(continued)

34
