Toshiba 14AF45C, 20AF45C appendix Setting the sleep timer, Using the closed caption feature

Page 22

Setting the sleep timer

You can set the TV so it turns off automatically.

To set the sleep timer:

Repeatedly press SLEEP on the remote control to set the length of time until the TV turns off. The clock will count down 10 minutes for each press of the SLEEP button (120, 110, ...10, 0). After the sleep time is programmed, the display will appear briefly every ten minutes to remind you that the sleep timer is operating.

To confirm the sleep timer setting:

Press SLEEP one time. The remaining time will be momentarily displayed.

To cancel the sleep timer:

Repeatedly press SLEEP until the display turns to 0.

Using the closed caption feature

The closed caption feature has two options: captions or text. A caption is a printed version of the dialogue, narration and/or sound effects of a program. Text is information not related to the program that appears on half of the TV screen when available.

To view captions or text:

1.Select the desired program. Closed captioned programs are usually marked in your local TV listing as “CC.”

2.Press CAP/TEXT repeatedly to select caption or text mode.

Sleep

1/2

CAP/TEXT

16:9

16:9

Using the TV’s Features

CAPTION CH1

TEXT CH1

3. Press 1/2 to select the caption or text channel.

CAPTION CH2

TEXT CH2

4.To turn off the closed caption feature, press CAP/TEXT repeatedly until captions or text no longer display on-screen.

Changing the picture size

You can change the picture size to 16:9 (widescreen) style.

To view 16:9 style:

Select the desired program, then press 16:9. The picture size will be displayed 16:9 style. “16:9” will appear on the screen for approx. 4 seconds.

To cancel 16:9 style:

Press 16:9 again. The picture size will return to 4:3 style.

16:9

4:3 Normal

16:9 Widescreen

Note:

A closed caption signal may not be decoded in the following situations:

•When a video tape has been dubbed.

•When the signal reception is weak.

•When the signal reception is non-standard.

When you select the text mode, the text screen always appears as a black box. When there is no signal, however, the text screen will not display text characters. Repeatedly press CAP/TEXT until the box disappears.

NOTICE OF POSSIBLE ADVERSE EFFECTS ON TV PICTURE TUBE

Avoid displaying stationary images on your TV screen for extended periods of time. Fixed (non-moving) images (such as still PIP/POP windows of black/gray bars in wide-screen picture or PIP/POP formats) can become permanently ingrained in the picture tube. This type of damage is NOT

COVERED BY YOUR WARRANTY.

22

J3S00221A(E)_P14-22

22

11/01/2005, 12:55 PM

Page 21 Page 23
Image 22
Page 21 Page 23
Contents 14AF45C 20AF45C Child Safety Important Safety Instructions Care Auto power off Adjusting the channel settingsUsing the Lock menu Troubleshooting Specifications Limited WarrantyExploring your new TV Welcome to ToshibaSelecting a location for the TV Connecting a VCR Connecting your TVStereo VCR Connecting a cable converter box Converter/Descrambler Splitter Switch a BConnecting a DVD player/satellite receiver and a VCR Connecting a camcorder You will need One set of standard A/V cablesLearning about the remote control Using the remote controlInstalling the remote control batteries To install the batteriesTo select a language Setting up your TVChanging the on-screen display language Press MENU, then press a or b until the Option menu appearsProgramming channels automatically Adding channels to the TV’s memoryChanging channels Adding and erasing channels manuallySwitching between two channels Using the TV’s featuresAdjusting the channel settings Programming your favorite channelsSelecting a PIN code Using the Lock menuTo select your PIN code and access the Lock menus To clear your favorite channelsLocking channels Setting the GameTimerTM Locking video inputTo create channel labels Labeling channelsTo erase channel labels Setting the on timer Setting the clockSetting the ON/OFF timer To set the clock Example 830 AMTo set the off timer Example Turning off the TV at 1130 PM Setting the off timerTo cancel the on timer To cancel the off timerWatching video input Specifying the ColorStream settingDisplaying on-screen information Using the closed caption feature Setting the sleep timerChanging the picture size To adjust the sound quality Adjusting the soundAdjusting the sound quality Muting the soundUsing the surround sound feature Auto power offUnderstanding the Power Return feature Using the StableSound featureMode first see TroubleshootingProblem Solution For several hours before turning it on againSpecifications 14AF45C 20AF45CLimited Canada Warranty Service Centers

14AF45C, 20AF45C specifications

Toshiba has long been a renowned name in the world of electronics, particularly in the realm of televisions. Among its notable offerings are the Toshiba 14AF45C and 20AF45C, two CRT (cathode-ray tube) television models that encapsulate the nostalgia of classic television experiences while still delivering reliable performance for viewers.

The Toshiba 14AF45C features a 14-inch screen, making it a compact option for those with limited space or for use in secondary rooms such as bedrooms or kitchens. It offers viewers a resolution of 400 lines, providing a crisp and clear picture quality that is characteristic of CRT technology. The model is equipped with a standard tuner, allowing users to access regular broadcasting channels without the need for additional equipment. A key feature of the Toshiba 14AF45C is its user-friendly interface, designed with simplicity in mind for a hassle-free viewing experience.

On the other hand, the Toshiba 20AF45C, with its 20-inch screen, is designed for a more immersive viewing experience. This model enhances the visual quality with an increased resolution, alongside the same reliable standards offered by its smaller counterpart. The 20AF45C also comes with stereo sound capabilities, providing a richer and more engaging audio experience. This feature is particularly appealing for users who enjoy watching movies or television shows with a more surround-sound feel.

Both models boast a sleek and classic design that seamlessly fits into a variety of room aesthetics. Their lightweight build allows for easy positioning, whether on a stand or mounted in a corner. Additionally, these models share several common features, such as multiple inputs, including composite and RF inputs, enabling connection to external devices like VCRs, game consoles, or DVD players, thus enhancing versatility.

Toshiba’s commitment to quality is evident in the durable construction of both the 14AF45C and 20AF45C, ensuring longevity even with regular use. The energy efficiency of these models is worth noting, as CRT televisions typically consume less power compared to some of the modern LCD variants, contributing to lower electric bills.

While flat-screen technologies dominate the current market, the Toshiba 14AF45C and 20AF45C remain classic choices for those who appreciate the warm glow and rich colors produced by CRT displays. They serve as a testament to Toshiba's legacy in delivering dependable and enjoyable viewing experiences in the world of home entertainment.
