Toshiba 14AF45C, 20AF45C Adjusting the sound, Muting the sound, Selecting stereo/SAP broadcasts

Page 23

Adjusting the sound

Muting the sound

Press MUTE to temporarily turn off the sound. While the sound is off, the screen will display the word MUTE in the lower right-hand corner. To restore the sound, press MUTE again.

Selecting stereo/SAP broadcasts

You can listen to high-fidelity stereo sound with the Multi-channel TV Sound (MTS) feature. MTS can also transmit a second audio program (SAP) containing a second language or other audio information.

When the TV receives a stereo or SAP broadcast, the word STEREO or SAP appears on-screen every time the TV is turned on, the channel is changed, or the RECALL button is pressed.

The MTS feature is not available in the VIDEO mode.

You can leave your TV in STEREO mode because it will automatically output stereo or monaural sound, depending on the broadcast type. If the stereo sound is noisy, select MONO to reduce the noise. The word STEREO or SAP is displayed in light blue when the TV receives the signal.

To select the desired MTS setting:

Repeatedly press the MTS button to select either STEREO, SAP, MONO+SAP, or MONO. If the current program is not available in stereo or SAP, the setting will not be available when you press the MTS button.

Adjusting the sound quality

You can change the sound quality of your TV by adjusting the bass, treble, and balance.

To adjust the sound quality:

1. Press MENU, then press a or b until the AUDIO menu appears.

















CH










































AUDIO

SETUP

OPTION





BASS







32







TREBLE







32







BALANCE





0



SURROUND

OFF

STABLE SOUND OFF

SELECT



ADJUST

2.Press c or d to highlight the item you want to adjust.

3.Press a or b to adjust the level.

















CH










































AUDIO

SETUP

OPTION















BASS







32

TREBLE







32







BALANCE





0



SURROUND



OFF

STABLE SOUND OFF

SELECT



ADJUST

a makes the sound quality weaker or decreases the balance in the right channel, depending on the item selected.

b makes the sound quality stronger or decreases the balance in the left channel, depending on the item selected.

23

Recall

Mute

MTS

STEREO

SAP

MONO

MONO + SAP

If the current program is not broadcasting either stereo or SAP, those settings will not be available when you press the MTS button.

c d a b

Menu

Reset

Note:

To reset the audio adjustments to the factory settings, press RESET.

Safeguards

Important

ToshibaWelcome to

yourConnecting TV

Remote ControlUsing the

your TVSetting up

FeaturesUsing the TV ’s

Appendix

J3S00221A(E)_P23-BACK

23

11/01/2005, 12:56 PM
