Advanced Features

xx The power-saving mode of some external hard disk drives may be released automatically when connected to the TV. xx If a USB extension cable is used, the USB device may not be recognized or the files on the device may not be read.

xx If a USB device connected to the TV is not recognized, the list of files on the device is corrupted or a file in the list is not played, connect the USB device to the PC, format the device and check the connection.

xx If a file deleted from the PC is still found when Media Play is run, use the “Empty the Recycle Bin” function on the PC to permanently delete the file.

¦¦ Screen Display

Move to the desired file using the up/down/right/left buttons and then press the ENTEREor (Play) button. The file is played.

Supports the View Devices and Home in Media Play homepage.

Information:

You can ascertain the selected file name and the number of files and page.

Sort List Section: Displays the sorting standard.

The sorting standard is different depending on the contents.

Videos

/Movie 01.avi



1/1 Page





Movie 01.avi

Movie 02.avi







Jan.10.2010



Jan.10.2010





Movie 03.avi

Movie 04.avi







Jan.10.2010



Jan.10.2010





Movie 05.avi

Movie 06.avi







Jan.10.2010



Jan.10.2010





Movie 07.avi

Movie 08.avi







Jan.10.2010



Jan.10.2010





Movie 09.avi

Movie 10.avi







Jan.10.2010



Jan.10.2010

SUM

Change Device

Select

Sorting TTools

File List Section:

You can confirm the files and groups that are sorted by category.

Operation Buttons

Red (Change Device): Selects a connected device.

BGreen (Preference): Sets the file preference. (not supported in Basic view)

Yellow (Select): Selects multiple files from file list. Selected files are marked with a symbol.

Blue (Sorting): Selects the sort list.

TTools: Displays the option menu.

Using the (REW) or µ(FF) button, file list can move to next or previous page.

Videos

Playing Video

1.Press the ◄ or ► button to select Videos, then press the ENTEREbutton in the Media Play menu.

2.Press the ◄/►/▲/▼ button to select the desired video in the file list.

3.Press the ENTEREbutton or (Play) button.

–– The selected file is displayed on the top with its playing time.

––If video time information is unknown, play time and progress bar are not displayed.

––During video playback, you can search using the ◄ and ► button.

In this mode, you can enjoy movie clips contained on a Game,

but you cannot play the Game itself.00:04:03 / 00:07:381/1

yy Supported Subtitle Formats

Movie 01.avi

Name

File extension

Format







MPEG-4 time-based text

.ttxt

XML

SAMI

.smi

HTML

SubRip

.srt

string-based







SubViewer

.sub

string-based

Micro DVD

.sub or .txt

string-based







SUM

EPause LJump TTools RReturn

28 English
