Philips DVP3136/94, SL-0721/94-2 user manual Specifications, Audio Format

Page 43

Specifications

TV STANDARD

(PAL/50Hz) (NTSC/60Hz)

Number of lines

625

525

Playback



Multistandard (PAL/NTSC)

VIDEO PERFORMANCE



Video DAC



14 bit



YPbPr



0.7 Vpp ~ 75 ohm

Video Output



1Vpp ~ 75 ohm

VIDEO FORMAT



Digital



MPEG 2 for DVD,SVCD

Compression



MPEG 1 for VCD

DVD



50Hz

60Hz

Horiz. resolution

720 pixels

720 pixels

Vertical resolution

576 lines

480 lines

VCD



50Hz

60Hz

Horiz. resolution

352 pixels

352 pixels

Vertical resolution

288 lines

240 lines

AUDIO FORMAT



Digital

MPEG/ AC-3/

compressed







Digital



PCM



16, 20, 24 bits







fs, 44.1, 48, 96 kHz



MP3 (ISO 9660)

96, 112, 128,







256kbps &







variable bit rate







fs, 32, 44.1, 48 kHz

Analog Sound Stereo

Dolby Surround compatible downmix from Dolby Digital multi-channel sound

AUDIO PERFORMANCE

DA Converter

24 bit, 192 kHz

DVD

fs 96 kHz

4Hz- 44kHz



fs 48 kHz

4Hz- 22kHz

SVCD

fs 48 kHz

4Hz- 22kHz



fs 44.1kHz

4Hz- 20kHz

CD/VCD

fs 44.1kHz

4Hz- 20kHz

Line Output





Signal-Noise (1kHz)



> 70 dB

Dynamic range(1kHz)

> 60 dB

Crosstalk (1kHz)



> 70 dB

Distortion/noise (1kHz)

>- 65 dB

Speaker Output





Signal-Noise (1kHz)



> 70 dB

Dynamic range (1kHz)

> 60 dB

Crosstalk (1kHz)



> 60 dB

Distortion/noise (1kHz)

>- 62 dB

Speaker Power Output



@ 10%THD



<=10W rms/ch





(2 channels)

Frequency Response

20Hz-20kHz

MPEG MP3



MPEG Audio L3

CONNECTIONS

YPbPr Output

Cinch 3x

Video Output

Cinch (yellow)

Audio Output (L+R)

Cinch (white/red)

Digital Output

1 coaxial



IEC60958 for CDDA /



LPCM



IEC61937 for MPEG 1/2

6 channal analog output



Audio Front L/R

Clinch (white/red)

Audio Rear L/R

Clinch (white/red)

Audio Center

Clinch (blue)

Audio Subwoofer

Clinch (black)

2 channel speaker output



Audio +RCH- Clip (red/black)

Audio +LCH- Clip (red/black)

CABINET





Dimensions (w x h x d)

360 x 37 x 237 mm

Weight



Approximately 2 kg

POWER CONSUMPTION

Power Supply Rating



110V – 240V;





50/60Hz

Power consumption



< 40 W

Power consumption in

< 2 W

Standby mode





43

English

dvp3136_94_eng 4.indd 43

2007-06-05 9:58:33 AM

Image 43
