Switching on and set up the TV

Before you switch on the TV, check that the AC power cord is properly connected. Press .POWER at the right side of the TV, or press . on the remote control.The TV normally takes 25-30 seconds to start up and the following screen appears the first time you turn on the TV.

InitialI iti l Setupt









Select your menu language.



English















Seleccione el idioma para el menú.



Español









Sélectionnez la langue du menu.







Français









Select

OK OK

MENU

Skip

Follow the on-screen instructions to select your language and complete your TV setup. Installation takes approximately 10 minutes.

Press Í or Æ to select the desired mode for energy saving, then press OK.

InitialI iti l Setupt

Select “Retail” or “Home” for your location.

Retail

Home

Select

OK OK

SETUP

Exit

Select [Retail] if you want backlight to be brighter. Select [Home] to reduce the power consumption.

You must set [Home]. Otherwise, the settings of picture and sound quality you adjusted will not be memorized after you turn off the unit.

Select [Retail], the unit will be set up with predefined setting for retail displays. In this setting, the power consumption may possibly exceed the limited requirement of the ENERGY STAR® qualification.

Select [Home], the unit is set to maximize the energy efficiency for home setting and it can be adjusted through a choice of picture and sound quality according to your preference.

Press OK to begin [Settings assistant].

Settingstti assistanti t t

Settings assistant helps you customize picture settings. You will see a series of test pictures where the right side and left side differ. Select the side that is most pleasing to you with the Left/ Right keys.



BACK

Back

MENU



OK Next

Exit









Press Í or Æ 5 times to select the side of the pictures that is the most pleasing to you. then press OK.

E n g l i s h

Left side



Right side







1/5 Select the picturei settingi thatt t you preferf ..

Select

BACK

Back

MENU

OK Next

Exit

Press OK to finish [Settings assistant].

Settingstti assistanti t t

You have set up your viewing preferences.



OK Store

BACK

MENU





Back

Exit









Finish the Setup.

Note

If you are not receiving a signal from your cable service, contact the CATV provider.

If you press . or MENU during autoprogram, this setting will be canceled.

The initial autoprogram function can be executed for either [Antenna] or [Cable] only once.When you change the connection (Antenna / Cable), set autoprogram again. (Refer to page 24.)

If there is no signal input from the antenna terminal and no operation for several seconds after you turn on the TV, [Helpful Hints] appears. Follow the instructions listed on the TV screen.

EN 11
