Philips LC07 DVB DFU manual ATS Automatic Tuning System feature

Page 31

20Automatic tuning of analogue programmes

This menu allows you to automatically search for all the analogue programmes available in your region.

Before you automatically search for all the analogue programmes, ensure the TV is in analogue mode. If it is in digital mode, press

the(Analogue / Digital) key to enter the analogue mode.

Press the key.

Main


Brightness

Sound

Colour

Features

Contrast

Install

Sharpness



Colour Temp



Contrast+



NR

Press the Î / ï key repeatedly to

select Install and the Æ / key to enter the Install menu.

Main


Auto Store



Sound

Manual Store



Features

Sort



Install

Name





Fav. Program









Press the ï key to select Auto Store

and the Æ / key to start automatic searching of the channels. All the available TV programmes will be stored. This operation takes a few minutes.The display shows the progress of the search and the number of programmes found.

























































Auto Store









English



Program

3









TV

196 MHz











































































IMPORTANT

To exit or interrupt the search before it

is completed, press the key. If you interrupt search during auto store, not all channels will be stored. For all channels to be stored, you need to do a complete auto store search again.

Note

ATS (Automatic Tuning System) feature

If the transmitter or cable network sends the automatic sort signal, the programmes will be numbered correctly. In this case, the installation is complete. If this is not the case, you can use the Sort menu to number the programmes to your preference.

ACI (Automatic Channel Installation) feature

If a cable system or a TV channel which broadcasts ACI is detected, a programme list appears.Without ACI broadcast, the channels are numbered according to your language and country selection.You can use the Sort menu to renumber them.

Note

You cannot change the Language or Country in Analogue mode. If you want to change the Language or Country, you have to exit Analogue mode and enter into Digital mode to do so (refer to “Preferences” on page 19).

27

Page 30 Page 32
Image 31
Page 30 Page 32
Contents Page Page Country Number Tariff Austria 0810 Recycling Table of contents English Electric, Magnetic Electromagnetic Fields EMF IntroductionImportant information Stationary images on the TV screen TipDigital or Analogue channels? What is digital TV?General SafetyCare of the screen Overview of television keys and connectors Getting started Connecting and Disconnecting the mainsSwitching on the TV Using the Remote ControlCancel Sound modeSubtitles mode Analogue or Digital modeMute Volume + VOLTeletext Digital menuOverview of Digital main menu and sub-menus Setup Favourites ListInformation System software Setup Preferences LanguageAccess restrictions LocationTest reception Installation Service listsSwitching on the TV for the first time Understanding the information on the banner Symbols descriptionRearrange services Service listsView new TV channels or Listen to new Radio stations Reinstall all services 10.1 Add new servicesSelect Reinstall all services ï and press Æ key Select Manual install services ï and press Æ key Manual install servicesTest reception Select Language or Location ï and press Æ key Language default settingsLocation settings PreferencesSet pin code protection menu Access restrictionsSelect radio stations use the Î ï Select TV channels use the Î ï keysOff Air Downloading of new software InformationSubtitle language use the Î ï keys Using the Options menuTV Guide Preset/Servcie Now NextAvailable in U.K. only Digital teletext MhegInserting the CAM Conditional Access Module menuACI Automatic Channel Installation feature ATS Automatic Tuning System featureProgram No Manual Store and the Æ / key to enter Manual Store menuSystem SearchProgramme Sort Naming of Channel Selecting your Favourite Programmes Features and the Æ/ key to enter Features menu 25.1 TimerClear All ParentalLock Program Change CodeChild Lock Lock modeActive Control and press the Æ Description of the Picture settings Picture and Sound settingsDescription of the Sound settings Smart Picture and Sound Picture Formats Teletext Favourite pages Hidden informationEnlarge a Picture/TeletextUsing the TV as a PC Monitor Sound menu Connecting the HD equipmentHD mode Control TV settings whileMode Selection in Features menu Selection modeSupported input formats Models only With the aerial cable only Connecting other equipmentConnect VCR or DVD recorder With a EurocableConnect a satellite receiver With a Eurocable With Component Video connectorsConnect 2 VCRs or VCR and DVD recorder With Eurocables With the aerial cables onlyDVD VGA connection is not supported PC equipped with a DVI connectorSupported PC resolutions Connect a PCAudio L / R inputs Audio L and Audio RTroubleshooting Powered by set Symptom Possible solutions No digital channelsPicture in HD mode Bottom of screen PC mode AC3 not availableProvides an uncompressed, all digital audio/video GlossaryGeneral Points

LC07 DVB DFU specifications

The Philips LC07 DVB DFU is a cutting-edge digital set-top box designed to enhance your television viewing experience. As a key component in the transition to digital TV broadcasts, this device offers viewers an array of features suited for high-quality audio and video experiences. One of its primary functions is to receive digital terrestrial television signals, providing users with access to a multitude of channels without the need for cable or satellite subscriptions.

Equipped with advanced DVB-T2 technology, the Philips LC07 ensures compatibility with the latest broadcasting standards, enabling users to enjoy a wider range of channels and better signal quality. This technology also allows for improved compression methods, resulting in enhanced picture and sound clarity. With support for Full HD resolution, the Philips LC07 guarantees stunning visuals, making it ideal for viewing movies, sports, and other high-definition content.

The device incorporates an easy-to-navigate user interface, allowing users to efficiently search for channels and customize their viewing preferences. With features such as Electronic Program Guide (EPG), users can easily access program information, set reminders, and schedule recordings. The LC07 also includes advanced parental control settings, enabling families to manage content accessibility effectively.

Connectivity is another key feature of the Philips LC07. With multiple ports, including HDMI, USB, and AV output, users can easily connect the device to a variety of televisions and playback devices. The USB port also provides the option for multimedia playback, allowing users to enjoy their favorite photos, music, and videos directly on their TV.

The device is designed with energy efficiency in mind, featuring low power consumption rates and compliance with environmentally friendly standards. This means that not only does it provide a great viewing experience, but it also contributes to saving energy and reducing your carbon footprint.

In summary, the Philips LC07 DVB DFU stands out within the digital set-top box market for its robust features, advanced technologies, and user-centric design. It successfully combines reliable performance with a rich set of functionalities that cater to modern viewing demands, making it a top choice for households looking to upgrade their television systems.
