38Product Specifications

Product Specifications

CPU

Intel® Celeron® processor











OS

Chrome OS













Memory

2 GB DDR3L













Storage

16 GB iSSD











Input / Output

Display Rear: USB 2.0 x 3, HDMI In x 1, Dc-In

Display Side: USB 3.0 x 1, HP out/Mic In combo











WiFi: 801.11 a/b/g/n (2.4 G / 5 G, Dual Band)

Network

LAN: Ethernet 10/100/1000 mbps



Bluetooth: 4.0











Webcam / MIC

Web CAM: 1.0 M / HD with Webcam LED(include indicator)

built-in MIC

















Audio

5 W x 2 built-in Stereo Speakers















21.5 inches (54.61 cm) TFT (Thin Film Transistor)

LCD Screen

Type



IPS LCD (Liquid Crystal Display) Screen





Diagonal length of the screen: 21.5 inch (54.61 cm)

















Pixel Pitch



0.08265 mm x 0.24795 mm









Maximum Resolution

1920 x 1080 @ 60 Hz







Video Signal (HDMI)

Recommended Resolution

1920 x 1080 @ 60 Hz







Horizontal Frequency

30 kHz to 83 kHz













Vertical Frequency



50 Hz to 75 Hz











Voltage



19 V 3.42 A









Power





On mode: 32 W (Typ)

Power consumption (Typ.)

Power Saving Mode ≤ 2.5 W









Off Mode ≤ 0.5 W







AC/DC adaptor

DA-65G19 manufactured by ASIAN POWER DEVICES INC.

Output: 19 V DC

3.42 A













Stand Angle Adjustment

Forwards/Backwards: -5 ° to 25 ° (Head)









Environmental Conditions

Operating Condition



Temperature: 10 °C to 35 °C, Humidity: 10 % to 80 %







Storing Condition



Temperature: -20 °C to 60 °C, Humidity: 5 % to 90 %













Monitor Size (Width x Height x Depth)

Dimension

With Stand



528.6 mm x 396.8 mm x 189.2 mm











Without Stand



528.6 mm x 320.4 mm x 43.5 mm









Weight (With Stand)

4.3 kg













The product specifications are subject to change without prior notice for performance improvement.
