42 Troubleshooting

Monitor Troubleshooting



The screen is blank





Is the product's power cord connected

•• Check if the power cord is connected correctly to a wall outlet.

correctly?







Is the power lamp on?

•• Check the Power button.





Is the power on and the power lamp is lit

•• Adjust the screen brightness and contrast.

either blue or green?







Is the power lamp blinking?

•• The power lamp blinks when the Internet Monitor is in standby



mode. When you press the power button, the monitor turns on



again within 2 to 3 seconds. Using a keyboard or mouse does



not exit standby mode.





Do you see the Monitor Frequency

•• This occurs when the signal sent by the PC (video card) exceeds

Range Exceeded message on the screen?

the range of horizontal or vertical frequency supported by the



monitor, so check the Product Specificationsof this manual



and change the settings.





Do you see the Check Signal Cable

•• This occurs when the signal cable between the PC and the

Connection message on the screen?

monitor is not correctly connected or unplugged, so check and



reconnect the signal cable.







There are afterimages on the screen





Are there afterimages on the screen even

•• Please be careful as displaying a fixed image on the screen for

after turning the monitor off?

a prolonged period of time can damage the monitor and leave



afterimages on the screen. Use screen savers to extend your



monitor’s working life.





yy NOTE

Vertical Frequency

yy A monitor screen must be refreshed dozens of times every second like a fluorescent lamp to allow users to see the picture.

yy This rate of screen refresh is called the Vertical Frequency or Refresh Rate, and is measured in Hz.

Horizontal Frequency

yy The time taken to display the full length of a single horizontal line on the screen is called the horizontal cycle. The Horizontal Frequency, measured in kHz, is the inverse of the horizontal cycle and shows the number of horizontal lines displayed on the screen every second.

The screen is unstable and shakes. / The screen shows ghost images.

Did you set the correct screen resolution? •• Refer to Using the Monitor > Setting the Resolution and set the screen to the recommended resolution.

Image 42
