Sony SNC-CS3P Controlling the Monitor Image, Monitor Image Section, Selecting the frame rate

Page 11

Monitor Image Section

The image shot by the camera is shown here.

Controlling the Monitor Image

You can control the monitor image from the image control section on the main viewer page.

Image control section

Selecting the frame rate

Click the down-arrow button in the Frame rate box and select the frame rate with which the images are transmitted, from the drop-down list.

You can select the frame rate from among the following: SNC-CS3N:

1, 2, 3, 4, 5, 6, 8, 10, 15, 20, 25, Fastest

SNC-CS3P:

1, 2, 3, 4, 5, 6, 8, 12, 16, 20, Fastest

The numbers indicate “FPS” (the number of frames transmitted per second).

With Fastest, the camera transmits the maximum number of frames possible for the connected line. The maximum frame rate is 30 FPS for the SNC-CS3N and 25 FPS for the SNC-CS3P.

Note

The frame rate options indicate the maximum number of frames that can be transmitted. The number of frames actually transmitted may vary depending on the network environments and camera settings (image size and image quality settings).

Selecting the view size

Click the down-arrow button in the View size box and select the view size from the drop-down list.

You can select the view size from among the following: Auto, 640 × 480, 320 × 240, 160 × 120

Auto is determined by the image size specified with Image size on the Camera setting page (see page 20).

Operating the Camera

Controlling the Monitor Image

11
