Canon 2805B002 manual CSetting Custom Functions, Changing Meters or Feet

Page 20

CSetting Custom Functions

You can customize Speedlite features to suit your preferences. Do it with Custom Functions.

1Press the <A> button for 2 sec. so that <u> is displayed.

2Select the Custom Function No.

Press the <9> button to select the Custom Function number.

3 Change the setting. Press the <8> button.

X The Custom Function number and setting number will blink.

X Press the <9> button to select “0” or “1”, then press the <8> button.

XAfter you set the Custom Function and press the <D> button, the camera will be ready to shoot.

Changing Meters or Feet

After step 1 above, press the <8> button for at least 2 sec. When the distance display blinks, press the <9> button to switch between meters and feet. Then press the <8> button.

20
