JVC LYT0087-001B Video Recording Basic Features, DATE/TIME Feature Purpose Operation, Display

Page 18

18EN

VIDEORECORDINGBasicFeatures(cont.)

DATE/TIME

FEATURE:

PURPOSE:

OPERATION:

Date/Time/Character Insert

To display the date and time in the viewfinder or on a connected colour monitor, as well as to record them manually or automatically.

1) Turn the Select Dial to any

position except AUTO LOCK.

2) Choose a display mode by

pressing DATE/TIME repeatedly

while in Record-Standby to cycle

Select Dial

Date display

Time display

Display

NOTES:

through the modes as shown in the

illustration to the left.

You should have already

performed the Date/Time Setting

procedure (pg. 9). If you

haven’t, do so first.

DISPLAY

The selected display can be

recorded.

If you don’t want to record the

display, select the Date-off mode

before shooting.

If you want to delete the display

Date/Time display

Auto Date



Date-off mode

Record mode



(No display)

The characters you have set using

Character Generator (pg. 27)

Date display



Auto Date Record mode

25.12.98AUTO DATE

Auto date record mode

during shooting, press DATE/TIME.

To recall the display, engage the

Record-Standby mode and press

DATE/TIME repeatedly until the

desired display appears.

Even if you shoot with the date/

time displayed during Digital Still

Camera Shooting, they will not be

recorded.

AUTO DATE RECORD

Your camcorder automatically

records the date for about 5

seconds after recording is initiated

in the following situations:

After changing the date.

After loading a cassette.

After Auto Date Record mode is

Time display

22:50:00

Date/Time display

25.12.98

Auto date record executed

selected by pressing DATE/TIME.

In this mode, the date is replaced after 5 seconds with “AUTO DATE” but this is not recorded.

Setting the Select Dial to AUTO LOCK always engages the Auto Date Record mode, and disables all other modes.

25.12.9822:50:00
