RCA L37WD23 Buttons On Your TV, Scans down through the channel list. In the TV menu system

Page 20

Connections and Setup

MENU

▲

CH ▲

▲

VOL

▲

Buttons On Your TV

INPUT/OK

If you cannot locate your remote, you can use the buttons on your TV to operate many of the TV’s features.

Models L26WD22 and L32WD22 buttons are located on the right side. Models L26WD23, L32WD23, and L37WD23 buttons are located on the top panel.

MENU Displays the TV Main menu. If the main menu is displayed, exits the menu; if a sub menu is displayed, takes you back to the previous menu.

CH

>

Scans down through the channel list. In the TV menu system,





acts like the down arrow button on the remote control and adjusts menu controls.

CH > Scans up through the channel list. In the TV menu system, acts like the up arrow button on the remote control and adjusts menu controls.

POWER Turns the TV on and off.

VOL < Decreases the volume. In the TV menu system, acts like the left arrow button on the remote control and adjusts menu controls.

VOL > Increases the volume. In the TV menu system, acts like the right arrow button on the remote control and adjusts menu controls.

INPUT/OK (only available on models L26WD23, L32WD23, and

L37WD23) Displays the available video input channels- Watch TV, Composite, S-Video, Composite (Side), S-Video (Side), Component 1, Component 2, VGA, HDMI1 and HDMI2. When in the menu system, displays sub-menus and selects the highlighted item.

20

Chapter 1
